Page 888 - MiSUMi FA Mechanical Components Economy Series

Slide Rails Three Step Slide Medium Load Type (Width:36mm, Stainless Steel)

Rail Length L 304.8mm, Stroke ST 327.2mm

Shipping
99.05 MYR from
1 day

Handles For price with different specification, please check our website

Pull-out: Unavailable
P.825
Rail Length L±1
(15.9) D
Hinges C B
A
P.841 19.1 111.1
25.4 12.7 Access Hole 5.3 4.5
Knobs 35.3 5.3 4.5 4.5 5.3

P.858 4.5 5.3 12.7 25.4
111.1
Linear slide rail A B C

D
P.876 Stroke ST±3 15.9 Rail Length L±1
17 .Material: Slide Rail : Stainless Steel
Handles / Hinges / Knobs / Slide Rails How to create a Inch Length Length Stroke A B C D (N/2 pcs)
Ball
: SUS440C
Rated
Rail
Load
ST
Mark
model
L
Y12
355.6
520
200.0
311.1
323.8
378.0
Y14 304.8 327.2 - 149.2 260.3 273.0 529
Y16 406.4 428.4 250.8 361.9 374.6 503
MISUMI WEB
1.Search this keyword Y18 457.2 479.2 212.7 301.6 412.7 425.4 494
slide rail 3 step
2.Select Economy series Y20 508.0 530.0 238.1 352.4 463.5 476.2 476
Brand
MISUMI Y22 558.8 580.8 263.5 403.2 514.3 527.0 450
Economy series
Y24 609.6 631.6 288.9 454.0 565.1 577.8 432
Y26 660.4 682.4 314.3 504.8 615.9 628.6 415
Y28 711.2 733.2 339.7 555.6 666.7 679.4 397
&Use M4 round head screws or small clamping screws for mounting slide rails.
&When it is installed horizontally, the load capacity is reduced to about 25% of the rated value (reference).
How to create Configure Clear All
a model Step Search on MISUMI official website Step Select Brand Brand
1 slide rail 3 step 2 MISUMI MISUMI
Economy Series
Input the keyword and search on the website
Economy series
