Page 884 - MiSUMi FA Mechanical Components Economy Series

Slide Rails Three Step Slide Light Load Type (Width:27mm, Stainless Steel)

Rail Length L 406.4mm, Stroke ST 428.4mm,
Open-Close Retaining Not Provided

Shipping
113.12 MYR from
1 day

Handles For price with different specification, please check our website

Pull-out: Unavailable
P.825
Stroke ST±3 Rail Length L±1
Hinges B A 20 20 A B
19.1
100 100
P.841 5.3 20 20 5.3
9.5
Knobs 27

2×П4.5 4.5 12.5 Access Hole 4.5 2×П4.5
P.858
Linear slide rail 2 Normally closed state holding type
· Applying force of more than 2kg/pc (reference value) in the pull-out
direction can release holding.
so that the slide rail may be kept in the pull-out direction. Prevent the
P.876 Plate Spring Protrusion · When storing the rails, allow the protrusions to hook the plate spring
17 pull-out part from opening due to vibration, etc.
· When using linear type slide rails in a vertical or inclined state, install
a mechanism externally to prevent the rails from falling off .
Handles / Hinges / Knobs / Slide Rails How to create a Inch Length Mark Rail Length L Stroke ST A .Material: Slide Rail : Stainless Steel
: SUS440C
Ball
Rated Load
B
(N/2 pcs)
model
Y08 203.2 225.2 143.2 163.2 336
Y10 254.0 276.0 194.0 214.0 327

MISUMI WEB Y12 304.8 326.8 244.8 264.8 318
1.Search this keyword
slide rail 3 step
2.Select Economy series Y14 355.6 377.6 295.6 315.6 300
Brand
MISUMI
Economy series Y16 406.4 428.4 346.4 366.4 283
Y18 457.2 479.2 397.2 417.2 265

Y20 508.0 530.0 448.0 468.0 248
&Use M4 round head screws or small clamping screws for mounting slide rails.
&When it is installed horizontally, the load capacity is reduced to about 25% of the rated value (reference).

How to create Search on MISUMI official website Configure Clear All
a model Step Step Select Brand Brand
1 slide rail 3 step 2 MISUMI MISUMI
Economy Series
Input the keyword and search on the website
Economy series
