drylin R drylin R
®
®
®
®
shaft drylin R pillow blocks | Product range drylin R pillow blocks | Product range shaft
guides guides
Closed, anodised aluminium, floating pillow blocks Open, anodised aluminium, floating pillow blocks
A1
α
A1 Order key W d1 Order key
d1
Type Size Version 1 Type Size Version
1 H H
H 3
H H
3
H
A
A E1
E1 S1 ±3.0mm
±3.0mm
S1
2 L 2 E L
E Long design Floating bearing Long design Floating bearing
Closed iglidur ® J Liner Metric Inner Ø d1 0° 90° 180° Open iglidur ® J Liner Metric Inner Ø d1

®
®
● Compensation of parallelism errors up to 6mm 78) According to igus testing method u Page 260 78) According to igus testing method u Page 260
● Quick assembly even on raw profiles 82) Design tips u Page 186 82) Design tips u Page 186
Please note: Installation instructions u Page 187 Please note: Installation instructions u Page 187
● Compensation of parallelism errors up to 6mm
Floating bearing u Page 186 Floating bearing u Page 186
Dimensions [mm] Dimensions [mm]

d1 H H1 A E1 E2 S1 L A1 H3 Part No. d1 H H1 A E1 E2 S1 L A1 H3 W a Part No.
±0.01 ±0.15 ±0.15 ±0.01 ±0.15 ±0.15 -1 [°]
12 18 28 43 32 23 M5 32 20 11 RJUM-06-12-LL 12 18 24.5 43 32 23 M5 32 20 11 10.2 90 OJUM-06-12-LL
16 22 35 53 40 26 M6 36 26 11 RJUM-06-16-LL 16 22 30.5 53 40 26 M6 36 26 11 11.6 90 OJUM-06-16-LL
20 25 41 60 45 32 M8 45 32 12.5 RJUM-06-20-LL 20 25 37.0 60 45 32 M8 45 32 12.5 12.0 60 OJUM-06-20-LL
25 30 50 78 60 40 M10 58 40 15 RJUM-06-25-LL 25 30 44.0 78 60 40 M10 58 40 15 14.5 60 OJUM-06-25-LL
30 35 59 87 68 45 M10 68 48 15 RJUM-06-30-LL 30 35 52.5 87 68 45 M10 68 48 15 16.8 60 OJUM-06-30-LL
40 45 76 108 86 58 M12 80 62 20 RJUM-06-40-LL 40 45 69.0 108 86 58 M12 80 62 20 21.0 60 OJUM-06-40-LL
50 50 89 132 108 50 M16 100 78 24 RJUM-06-50-LL 50 50 80.0 132 108 50 M16 100 78 24 25.5 60 OJUM-06-50-LL

Technical data Technical data
Part No. d1 tolerance 78) Fmax. static Weight Part No. d1 tolerance 78) Fmax. static Fmax. static with Weight
82)
or dynamic 82) or dynamic 82) load at 180°
[mm] [N] [g] [mm] [N] [N] [g]
RJUM-06-12-LL +0.030 +0.088 560 50 OJUM-06-12-LL +0.030 +0.088 560 240 40
RJUM-06-16-LL +0.030 +0.088 920 80 OJUM-06-16-LL +0.030 +0.088 920 400 70
RJUM-06-20-LL +0.030 +0.091 2,100 130 OJUM-06-20-LL +0.030 +0.091 2,100 900 115
RJUM-06-25-LL +0.030 +0.091 3,550 280 OJUM-06-25-LL +0.030 +0.091 3,550 1,520 240
RJUM-06-30-LL +0.040 +0.110 5,300 430 OJUM-06-30-LL +0.040 +0.110 5,100 2,280 370
RJUM-06-40-LL +0.040 +0.115 8,000 850 OJUM-06-40-LL +0.040 +0.115 8,000 3,800 750
RJUM-06-50-LL +0.050 +0.150 12,500 1,550 OJUM-06-50-LL +0.050 +0.150 12,500 6,100 1,400

Available with drylin liners (optional: J200/A180): Available with drylin liners (optional: J200/A180):
®
®
ASEAN 09/2023 ASEAN 09/2023

J E7 X J E7 X

236 Online tools and more information u www.igus-asean.com/drylinR 3D CAD files, prices and delivery time online u www.igus-asean.com/drylinR 237
