drylin R drylin R
®
®
®
®
shaft drylin R pillow blocks | Product range drylin R pillow blocks | Product range shaft
guides guides
Open, anodised aluminium housing, long design Open, anodised aluminium housing, long design
with manual clamp M KB
W S KL M KB S1
W S KL S1
W S Order key H H Order key
d1 Type Size H1 N2 N1 H1 N2 N1 Type Size Version
d1
H d1 H1 H1 ØS2 ØS2
H N1 N1 N2 N2 H1
M H N1 S2 N2 ØS W Ød1 ØS Ød1
S2
M
M S1 S2 L
S1
S1 L KL M KB
E2 E2 S1
H
E2 E2 L L N2 N1
E2 L Long design Inner Ø d1 E1 A E1 A H1 ØS2 Long design Inner Ø d1 Manual clamp
E1 Open iglidur ® J Liner Metric Open iglidur ® J ØS Liner Metric Ød1
E1
0° 90° 180° A E1
A
A L
®
78) According to igus testing method u Page 260 E2 78) According to igus testing method u Page 260
®
82) Design tips u Page 186 82) Design tips u Page 186
Please note: Installation instructions u Page 187 Please note: Installation instructions u Page 187
E1 A
Dimensions [mm] Dimensions [mm]

d1 H H1 A M E1 E2 S S1 S2 N1 N2 W a L Part No. d1 H H1 A M E1 E2 S S1 S2 N1 N2 W L KL KB Part No.
+0.01; -0.014 ±0.02 ±0.15 ±0.15 -1 [°] +0.01; -0.014 ±0.02 ±0.15 ±0.15 -1
12 18 28 43 21.5 32 23 8.0 M5 4.3 16.5 11 10.2 78 39 OJUM-06-12 12 18 28 43 21.5 32 23 8 M5 4.3 16.5 11 10.2 39 40 33 OJUM-06-12-HK
16 22 35 53 26.5 40 26 10.0 M6 5.3 21.0 13 11.6 78 43 OJUM-06-16 16 22 35 53 26.5 40 26 10 M6 5.3 21 13 11.6 43 40 33 OJUM-06-16-HK
20 25 42 60 30.0 45 32 11.0 M8 6.6 24.0 18 12.0 60 54 OJUM-06-20 20 25 42 60 30.0 45 32 11 M8 6.6 24 18 12.0 54 40 33 OJUM-06-20-HK
25 30 51 78 39.0 60 40 15.0 M10 8.4 29.0 22 14.5 60 67 OJUM-06-25 25 30 51 78 39.0 60 40 15 M10 8.4 29 22 14.5 67 65 46 OJUM-06-25-HK
30 35 60 87 43.5 68 45 15.0 M10 8.4 34.0 22 16.6 57 79 OJUM-06-30 30 35 60 87 43.5 68 45 15 M10 8.4 34 22 16.6 79 65 46 OJUM-06-30-HK
40 45 77 108 54.0 86 58 18.0 M12 10.5 44.0 26 21.0 56 91 OJUM-06-40 40 45 77 108 54.0 86 58 18 M12 10.5 44 26 21.0 91 65 46 OJUM-06-40-HK
50 50 88 132 66.0 108 50 20.0 M16 13.5 49.0 34 25.5 54 113 OJUM-06-50 50 50 88 132 66.0 108 50 20 M16 13.5 49 34 25.5 113 65 46 OJUM-06-50-HK

Technical data Technical data
Part No. d1 tolerance 78) Fmax. dynamic 82) Fmax. static 82) Weight Part No. d1 tolerance 78) Fmax. dynamic 82) Fmax. static 82) Clamp force Weight
p = 5MPa p = 35MPa p = 5MPa p = 35MPa axial
0º 90º 180º 0º 90º 180º [g] 0º 90º 180º 0º 90º 180º [N] [g]
OJUM-06-12 +0.030 +0.088 960 635 240 6,720 4,445 1,680 95 OJUM-06-12-HK +0.030 +0.088 960 635 240 6720 4445 1680 400 0.098
OJUM-06-16 +0.030 +0.088 1440 990 396 10,080 6,943 2,772 158 OJUM-06-16-HK +0.030 +0.088 1440 990 396 10080 6943 2772 400 0.164
OJUM-06-20 +0.030 +0.091 2250 1,800 900 15,750 12,600 6,300 266 OJUM-06-20-HK +0.030 +0.091 2250 1800 900 15750 12600 6300 400 0.275
OJUM-06-25 +0.030 +0.091 3625 2.953 1,523 25,375 20,670 10,658 530 OJUM-06-25-HK +0.030 +0.091 3625 2953 1523 25375 20670 10658 1,000 0.544
OJUM-06-30 +0.040 +0.110 5100 4,250 2,278 35,700 29,735 15,946 818 OJUM-06-30-HK +0.040 +0.110 5100 4250 2278 35700 29735 15946 1,000 0.832
OJUM-06-40 +0.040 +0.115 8000 6,810 3,800 56,000 47,660 26,600 1,485 OJUM-06-40-HK +0.040 +0.115 8000 6810 3800 56000 47660 26600 1,000 1.513
OJUM-06-50 +0.050 +0.150 12,500 10,750 6,125 87,500 75,265 42,875 2,750 OJUM-06-50-HK +0.050 +0.150 12500 10750 6125 87500 75265 42875 1,000 2.568

Available with drylin liners (optional: J200/A180): Available with drylin liners (optional: J200/A180):
®
®
ASEAN 09/2023 ASEAN 09/2023

J E7 X J E7 X
