drylin R drylin R
®
®
®
®
shaft drylin R quad blocks | Product range drylin R quad blocks | Product range shaft
guides guides
Closed design Open design
Order key Order key

Type Option Size Type Option Size

Quad block with RJUM bearings Aluminium housing Standard with RJUM-01 Inner Ø d1 Quad block with OJUM bearings Aluminium housing Standard with OJUM-01 Inner Ø d1

● Housing: Aluminium, equipped with four ● Housing: Aluminium, equipped with four
drylin R linear plain bearings Options: drylin R linear plain bearings Options:
®
®
01: Standard with RJUM-01 60° 01: Standard with OJUM-01
S 03: with RJUM-03 W S 03: with OJUM-03
M8x1 04: with RJM-01 d D1
d D1 M8x1
H H
H1 N H1 N
H3
A S1 Please note: A S1 Please note:
Installation instructions Installation instructions
u Page 187 u Page 187

E A E A

R R

Dimensions [mm] Dimensions [mm]
d D1 A H H1 H3 R N E S S1 Part No. Self- Solid plastic d D1 A H H1 W R N E S S1 Part No. Self-
Standard aligning bearings Standard aligning
with with with with with
RJUM-01 RJUM-03 RJM-01 OJUM-01 OJUM-03
8 16 65 23 11.5 8 32 11 55 4.3 M5 RQA-01-08 – RQA-04-08 12 22 85 30 18 14 42 13 73 5.3 M6 OQA-01-12 OQA-03-12
10 19 70 25 12.5 10 34 13 60 4.3 M5 RQA-01-10 RQA-03-10 RQA-04-10 16 26 100 35 22 17 54 13 88 5.3 M6 OQA-01-16 OQA-03-16
12 22 85 32 16 13 42 13 73 5.3 M6 RQA-01-12 RQA-03-12 RQA-04-12 20 32 130 42 25 17 72 18 115 6.8 M8 OQA-01-20 OQA-03-20
16 26 100 36 18 15 54 13 88 5.3 M6 RQA-01-16 RQA-03-16 RQA-04-16 25 40 160 51 30 21 88 22 140 9.0 M10 OQA-01-25 OQA-03-25
20 32 130 46 23 19 72 18 115 6.6 M8 RQA-01-20 RQA-03-20 RQA-04-20 30 47 180 60 35 21 96 26 158 10.5 M12 OQA-01-30 OQA-03-30
25 40 160 56 28 24 88 22 140 8.4 M10 RQA-01-25 RQA-03-25 RQA-04-25 40 62 230 77 45 27 122 34 202 13.5 M16 OQA-01-40 OQA-03-40
30 47 180 64 32 27 96 26 158 10.5 M12 RQA-01-30 RQA-03-30 RQA-04-30
40 62 230 80 40 35 122 34 202 13.5 M16 RQA-01-40 RQA-03-40 RQA-04-40

Are equipped with: Available with drylin liners (optional: J200/A180): Are equipped with: Available with drylin liners (optional: J200/A180):
®
®
ASEAN 09/2023 ASEAN 09/2023

RJUM-01 RJUM-03 RJM-01 J E7 X OJUM-01 OJUM-03 J E7 X

252 Online tools and more information u www.igus-asean.com/drylinR 3D CAD files, prices and delivery time online u www.igus-asean.com/drylinR 253
