drylin  R
            ®
                              ®
         shaft       drylin  R flanged linear plain bearings | Product range New                                                 Notes
        guides
                     Adapter with clip-in liners made from iglidur  W360 (precision),
                                                                             ®
                     round flange
                                                                    Order key


                                                              Type                       Size



                                                                                                   Option:
                                                                                                   T: Tandem


                                                                With flange  drylin ®  R  Clip-in liner  Metric  Tandem  Inner Ø d1
        ● 	Up to 50% lower clearance in operation                        iglidur ®  W360   Square design



                                        A-A ( 1 : 1 )  A-A ( 1 : 1 )  Bf
                                                    Bf
           A          A                              ts          ts
                                                 db       ds  db     ds
 dt      dt
 d1      d1                         d3  d2      d3  d2



    A           A
                                                B           B




        Dimensions [mm] - flanged linear plain bearing

         d1          d2       d3      dt       B       Bf       ts      db       ds    Part No.
         +0.01 +0.05  H7
         12          22       42      32       32       9      4.1      4.5     7.5    FRW360CM-01-12     New
         16          26       46      36       36       9      4.1      4.5     7.5    FRW360CM-01-12     New
         20          32       54      43       45      11      5.1      5.5     9.0    FRW360CM-01-12     New




        Dimensions [mm] - flanged linear plain bearing, tandem design
         d1          d2       d3      dt       B       Bf       ts      db       ds    Part No.
         +0.04 +0.01  H7
         12          22       42      32       57       9      4.1      4.5     7.5    FRW360CMT-01-12 New
         16          26       46      36       70       9      4.1      4.5     7.5    FRW360CMT-01-12 New
         20          32       54      43       80      11      5.1      5.5     9.0    FRW360CMT-01-12 New
