drylin A tg drylin
®
®
®
®
SLW drylin SLW | Linear modules | Product range drylin SLW | Linear modules | Product range SLW
kq
s
f
linear A sk linear
modules I+Hub modules
With ball bearing supported lead screw
AI
● Lower drive force T lt Order key
lt
● Optimised clearance lb E2 E3 lb
● Up to 1,500rpm (depending on length and load) Order example
d
®
● Aluminium drylin W guide rails, hard-anodised
● Quiet operation - reduced vibration of the overall
system E1
● Ball bearings in both shaft end supports
● Accessories available u Page 613
● Lead screw nuts are available separately Adjustable clearance
u Page 470
A tk I2
● Available with motor ts sg hw d2 Compact Ball bearing Dimension
kt
H
ha
A
tg kq s f
A
sk
l + stroke
I+Hub
Select versions and accessories online
u www.igus-asean.com/drylinSLW A tk I2
AI ts sg
lt T lt hw d2
E3 kt
lb lb
E2 H
ha
A d tg
kq s f
A
sk
Technical data and dimensions [mm] E1 I+Hub
Part No. Design 96) Max. Weight additional Max. static load capacity Max. Max. kt sk sg kq Øs d T l2 d2 d2 95) ha
AI
stroke length (per 100mm) axial radial speed feed rate ±0.1 lt Standard lt
T
[mm] [kg] [kg] [N] [N] [1/min] [m/min] lb E3 lb
E2
SLW-BB-0630 300 0.25 0.08 100 200 1,000 1.5 8.0 7.0 M4 2.0 4.5 6 Tr8x1.5 15 Tr08x1.5 – 9.5
d
SLWE-BB-1040 500 0.90 0.10 500 2,000 1,500 3.0 6.4 9.5 M6 4.4 6.6 10 Tr10x2 17 Tr10x2 6 h9 14.5
SLWE-BB-1080 500 1.10 0.20 500 2,000 1,500 3.0 6.4 9.5 M6 4.4 6.6 10 Tr10x2 17 Tr10x2 6 h9 14.5
E1
SLWE-BB-1660 750 1.80 0.30 700 2,800 1,500 6.0 8.6 11.0 M8 5.5 9.0 16 Tr14x4 20 Tr14x4 8 h9 18.5
SLW-BB-16120 New 750 1.90 0.40 700 2,800 186) 1,500 4.5 8.6 11.0 M8 5.5 9.0 16 Tr14x3 20 Tr14x3 8 h9 18.5
SLWE-BB-2080 900 3.30 0.40 1,250 5,000 1,500 6.0 8.6 14.0 M8 5.5 9.0 20 Tr18x4 26 12 h9 – 23.0
SLW-BB-25120 1,000 3.30 0.40 1,500 6,000 1,200 6.0 12.6 15 M10 5.0 11.0 25 Tr24x5 38 14 h9 – 30.0
Dimensions [mm]
Part No. A AI H E1 E2 E3 l hw f lt lb tk ts tg
-0.3 -0.3 ±0.15 ±0.15 ±0.15
SLW-BB-0630 54 60 20 40 45 51 112 18 1.2 26 14.0 11 6.8 M8x12
SLWE-BB-1040 74 69 29 60 60 56 129 24 1.5 30 19.0 11 6.8 M8x10
SLWE-BB-1080 108 100 29 94 94 87 160 24 1.5 30 19.0 11 6.8 M8x10
SLWE-BB-1660 104 100 37 84 86 82 170 35 1.5 35 22.5 15 9.0 M10x20
SLW-BB-16120 New 166 150 37 146 148 132 200 35 1.5 35 17.5 15 9.0 M10x20
SLWE-BB-2080 134 150 46 116 116 132 230 44 1.5 40 26.0 15 8.6 M10x15
SLW-BB-25120 200 150 60 173 173 128 220 55 2.5 49 17.5 20 13.5 M16x30
95) Version with turned lead screw end available
96) Double rail, square u Page 78, round u Page 84
186) Only bearing load without consideration of possible shaft deflection
187) Other carriage lengths: 200mm and 250mm ASEAN 09/2023 ASEAN 09/2023
