drylin drylin SAW | Linear modules | Product range drylin SAW | Linear modules | Product range drylin
®
®
SAW SAW
Robust design Reduced clearance with pretension in lead screw support and lead
screw nut
● Trapezoidal or high helix threads
● Ball bearing supported lead screw ● Lubrication and maintenance-free
● Rail profile in high design, extremely ● Quiet, reduced backlash
torsion-resistant ● Trapezoidal or high helix threads
®
● Aluminium drylin W guide rails, ● 3 carriage lengths (100/150/200mm)
hard-anodised E6 tk ts A-A ( 1 : 1.5 ) l2 with spring-loaded second lead tk ts A-A ( 1 : 1.5 ) l2
E6
A
A
● High strength kt screw nut kt
E5
E5
● Cost-effective and 100% lubrication- kq ● Liners made from wear-resistant kq
H
H
ha
free ha high-performance polymers
A
A
● Accessories available u Page 613 tg f sg sk hw ● For manual and electric adjustment tg f sg hw
A
A
sk
● Lead screw nuts are available even in multi-axis linear robots
separately u Page 470 Al Al
lt lt lt lt
lb E3 lb lb E3 lb
E2 E2
d d
T T
d2 d2
E1 E1

l + stroke l + stroke
tk tk
A-A (1 : 1.5)
A-A (1 : 1.5)
E6 ts A-A ( 1 : 1.5 ) l2 E6 ts A-A ( 1 : 1.5 ) l2
A A
kt kt
E5 E5
H kq H kq
ha ha
A tg f sg A tg f sg
A sk hw A sk hw
Technical data Technical data
Al
Al
Part No. Max. stroke length Weight Additional lt Max. rotational speed Max. static load capacity Part No. Max. stroke length Weight Additional Max. rotational speed Max. static load capacity
lt
lt
lt
lb E3 lb lb E3 lb
E2
[mm] [kg] (per 100mm) T d [rpm] E2 axial [N] radial [N] [mm] [kg] (per 100mm) T d [rpm] axial [N] radial [N]
SAW-0630 300 0.5 0.1 1,000 100 400 d2 SAW-1080-PL 750 1.9 0.2 1,500 750 2,000 d2
E1
SAW-0660 500 0.9 0.1 1,000 100 400 E1
SAW-1040 500 1.0 0.1 1,500 500 2,000
SAW-1080 750 1.9 0.2 1,500 750 2,000

SAW-1660 750 2.8 0.5 1,500 l + stroke 750 3,000 l + stroke
Dimensions [mm] Dimensions [mm]
Part No. A AI H E1 E2 E3 E5 E6 l lc hw f lt Ib Part No. A AI H E1 E2 E3 E5 E6 l lc hw f lt Ib
-0.3 -0.3 +0.15 +0.15 +0.15 -0.3 -0.3 +0.15 +0.15 +0.15
SAW-0630 54 60/100 32 40 45 51/91 11 23 112/152 92 30 13.5 26 10 SAW-1080-PL 108 100 58 94 94 87 – – 163 131.5 49 22.5 31.5 15.75
SAW-0660 85 100 38 71 76 91 – – 156 – 34 13.7 28 –
SAW-1040 74 69/100/150 50 60 60 56/87/137 20 40 129/160/210 91 45 22.5 30 19
SAW-1080 108 100 58 94 94 87 – – 163 131.5 49 22.5 31.5 15.75
SAW-1660 104 150 77 84 86 132 20 40 220 175 72 38.5 35 22.5

Part No. tk ts tg kt sk sg kq d T l2 d2 ha Part No. tk ts tg kt sk sg kq d T l2 d2 ha
±0.1 Ø ±0.1 Ø
SAW-0630 11 6.6 – 20 – M4 10 5 Tr8x1.5 15 Tr8x1.5 21.5 SAW-1080-PL 11 6.8 M8x20 18 9.5 M6 3.5 10 Tr12x3 17 Tr12x3 Ø8 h9 113) 37.5
SAW-0660 – – M8x12 20 7 M4 2 6 Tr10x2 15 Tr10x2 23.0 113) Lead screw end unmachined, also available with machined end
SAW-1040 11 6.8 M8x20 6.4 9.5 M6 3.5 10 Tr10x2 17 Tr10x2 Ø6 h9 113) 35.5
SAW-1080 11 6.8 M8x20 18 9.5 M6 3.5 10 Tr12x3 17 Tr12x3 Ø8 h9 113) 37.5
SAW-1660 15 9.0 M10x29 8.6 11 M8 5.5 16 Tr14x4 20 Tr14x4 Ø8 h9 113) 59.0

113) Lead screw end unmachined, also available with machined end ASEAN 09/2023 ASEAN 09/2023
