drylin drylin
®
®
®
®
SET drylin SET | easytube | Product range drylin SET | easytube | Product range SET
easytube easytube
easytube With flange
E4
sb s Order key d2 d2 Order key
l2
H h1 l2
Order example Order example
d2
ts h
A
l2
E1 h
E3
t E2
l
E1 h l + Hub

E2 A3 Dimension Shaft material s Dimension Shaft material With flange
lt easytube Al lt I + stroke easytube H

E1 A2 l + Hub
E3 l A
s
E4 ts
sb s
E5
H h1 H E3 E1
d2 E2
ts h
A
lt I + stroke A E5
l2
E3
ts lt Al lt A2
E2

● For simple adjustments E1 ● Flanged version for axial mounting E3 E1
● With protected lead screw lt Al lt ● Simple, smooth design E2
● Corrosion-free with stainless steel lead screw ● Accessories available u Page 613
● Lightweight due to aluminium and polymer A E5
● Temperature-resistant up to +60°C
● Accessories available u Page 613
lt Al lt A2

Technical data Technical data
Part No. Max. Aluminium shaft Max. static load capacity Part No. Max. Aluminium shaft Max. static load capacity
stroke length Weight shaft end supports additional axial radial stroke length Weight shaft end supports additional
axial radial
and guide carriage (per 100mm) and guide carriage (per 100mm)
[mm] [kg] [kg] [N] [N] [mm] [kg] [kg] [N] [N]
SET-12-AWM 200 0.05 0.03 10 20 SET-25-AWM-F 750 0.15 0.12 150 300
SET-25-AWM 750 0.15 0.12 150 300 SET-30-AWM-F 850 0.20 0.21 200 400
SET-30-AWM 850 0.20 0.21 200 400

Dimensions [mm] Dimensions [mm]

Part No. A Al H E1 E2 E3 E4 l h h1 lt ts Øs sb l2 d2 92) Part No. AI A A2 H E1 E2 E3 E5 l h lt ts Øs l2 d2 92)
SET-12-AWM 30 30 23.5 20 20 20 – 60 22 – 15 3.3 4.2 – 10 M4 SET-25-AWM-F 55 60 60 49 40 40 40 40 115 39 30 5.2 5.2 27 Tr10x2
SET-25-AWM 60 55 44 40 40 40 20 115 39 45 30 5.2 5.2 M4 17 Tr10x2 SET-30-AWM-F 55 60 80 59 60 40 40 40 125 39 35 6.5 5.2 30 Tr12x3
SET-30-AWM 80 55 49 60 40 40 20 125 39 50 35 6.5 5.2 M4 20 Tr12x3 92) Lead screw end unmachined
92) Lead screw end unmachined
ASEAN 09/2023 ASEAN 09/2023

562 Online tools and more information u www.igus-asean.com/drylinSET 3D CAD files, prices and delivery time online u www.igus-asean.com/drylinSET 563
