Low Cost drygear Apiro | Product range drygear Apiro | Product range New Low Cost
Automation Automation
Rack gears Rack gears with integrated planetary gearbox

RL-A14.0107 RL-A14.0109 RL-A16.0102.XX Gearbox technology
The rack gears allow different strokes in the application and ØT The Apiro rack and pinion gear with integrated planetary ØT
®
include rack and pinion elements. They are configurable in gearbox allows direct connection of NEMA stepper motors
different lengths - for pusher applications, for example. The or DC motors, creating a very compact unit.
version with coupling makes it easy to synchronise several H1 G 1 H2 H1 G 1 H2
rack and pinion gears. D1 ● Lubrication and maintenance-free D1
L1 L2 L1 L2
● Greater forces possible with the same installation
B1 B1
● Motor drive or manual drive space
● Modules can be connected in series or in parallel L3 ● High efficiency L3
● INI kit available for all options Order example ● High positioning accuracy
● Application temperature: +5°C to +50°C RL-A14.0107.3 ● Transmission: 4:1
(rack gear, 60mm stroke)

Technical data Technical data
Part No. Feed rate per rotation Backlash Max. load Weight Part No. Profile Axis distance Backlash Max. Feed rate per Weight
[mm] [°] [N] [g] diameter load rotation
RL-A14.0107. New 125.66 < 0.5 25 ab 330 [mm] [mm] [°] [N] [mm] [g]
RL-A14.0109. New 125.66 < 0.5 25 ab 330 RL-A16.0102. New 20 31 < 0.5 25 31.42 ab 280
RL-A14.0114. New 125.66 < 0.5 25 ab 330 Stroke lengths according to the additional table on the left

Dimensions [mm] Dimensions [mm]
Part No. T L1 H1 H2 B1 D1 G1 Part No. L1 L2 L3 H1 H2 B1 D1 G1 T
Ø Ø
RL-A14.0107. New 20 80 87 31 50 25 M3 RL-A16.0102. New 80 60 - 1,050 150 - 1,140 87 31 50 25 M3 20
RL-A14.0109. New 8 80 87 31 50 25 M3
RL-A14.0114. New 12 80 87 31 50 25 M3

Part No. L2 L3 Part No. L2 L3
add-on Stroke Total system length add-on Stroke Total system length
… 3 60 150 … 14 580 670
… 4 110 200 … 15 625 715
… 5 155 245 … 16 675 765
… 6 200 290 … 17 720 810
… 7 250 340 … 18 770 860
… 8 295 385 … 19 815 905
… 9 345 435 … 20 860 950
… 10 390 480 … 21 910 1000
… 11 440 530 … 22 955 1045
… 12 485 575 … 23 1005 1095 Delivery time
… 13 530 620 … 24 1,050 1140 ASEAN 09/2023 ASEAN 09/2023 2-3 days
