P. 1103
Inch Inch
®
®
iglidur Imperial product range | iglidur | Sleeve bearings Imperial product range | iglidur | Sleeve bearings iglidur
®
®
form S form S
Sleeve bearings (form S) d1 d2 b1 d1 3) Housing hole Shaft size Part No.
max. min. max. min. max. min.
f1 30° Chamfer in relation to d1 7/8 1 3/4 .8791 .8757 1.0005 .9997 .8741 .8729 A181SI-1416-12
d1 [inch] f [inch] 7/8 1 1 .8791 .8757 1.0005 .9997 .8741 .8729 A181SI-1416-16
Ø 0.040 - 0.236 0.012 1 1 1/8 1/2 1.0041 1.0007 1.1255 1.1247 .9991 .9979 A181SI-1618-08
Ø 0.236 - 0.472 0.019 1 1 1/8 3/4 1.0041 1.0007 1.1255 1.1247 .9991 .9979 A181SI-1618-12
d1 d2
0.5 Ø 0.472 - 1.18 0.031 1 1 1/8 1 1.0041 1.0007 1.1255 1.1247 .9991 .9979 A181SI-1618-16
Ø > 1.18 0.047 1 1/8 1 9/32 3/4 1.1288 1.1254 1.2818 1.2808 1.1238 1.1226 A181SI-1820-12
1 1/8 1 9/32 1 1.1288 1.1254 1.2818 1.2808 1.1238 1.1226 A181SI-1820-16
30°
b1
1 1/8 1 9/32 1 1/4 1.1288 1.1254 1.2818 1.2808 1.1238 1.1226 A181SI-1820-20
Image exemplary 1 1/4 1 13/32 3/4 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 A181SI-2022-12
1 1/4 1 13/32 1 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 A181SI-2022-16
1 1/4 1 13/32 1 1/4 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 A181SI-2022-20
iglidur A181 Chapter Page 401 1 1/2 1 21/32 1 1.5048 1.5008 1.6568 1.6558 1.4988 1.4972 A181SI-2426-16
®
1 1/2 1 21/32 1 1/2 1.5048 1.5008 1.6568 1.6558 1.4988 1.4972 A181SI-2426-24
d1 d2 b1 d1 3) Housing hole Shaft size Part No. 1 5/8 1 25/32 1 1.6297 1.6258 1.7818 1.7808 1.6238 1.6222 A181SI-2629-16
max. min. max. min. max. min. 1 5/8 1 25/32 1 1/2 1.6297 1.6258 1.7818 1.7808 1.6238 1.6222 A181SI-2629-24
1/8 3/16 3/16 .1269 .1251 .1878 .1873 .1243 .1236 A181SI-0203-03 1 3/4 1 15/16 1 1.7547 1.7507 1.9381 1.9371 1.7487 1.7471 A181SI-2831-16
3/16 1/4 1/4 .1892 .1873 .2503 .2497 .1865 .1858 A181SI-0304-04 1 3/4 1 15/16 2 1.7547 1.7507 1.9381 1.9371 1.7487 1.7471 A181SI-2831-32
3/16 1/4 3/8 .1892 .1873 .2503 .2497 .1865 .1858 A181SI-0304-06 1 7/8 2 1/16 1 1.8796 1.8757 2.0633 2.0621 1.8737 1.8721 A181SI-3033-16
1/4 5/16 3/8 .2521 .2498 .3128 .3122 .2490 .2481 A181SI-0405-06 1 7/8 2 1/16 2 1.8796 1.8757 2.0633 2.0621 1.8737 1.8721 A181SI-3033-32
1/4 5/16 1/2 .2521 .2498 .3128 .3122 .2490 .2481 A181SI-0405-08 2 2 3/16 1 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 A181SI-3235-16
5/16 3/8 1/4 .3148 .3125 .3753 .3747 .3115 .3106 A181SI-0506-04 2 2 3/16 2 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 A181SI-3235-32
5/16 3/8 3/8 .3148 .3125 .3753 .3747 .3115 .3106 A181SI-0506-06
5/16 3/8 1/2 .3148 .3125 .3753 .3747 .3115 .3106 A181SI-0506-08
3/8 15/32 1/4 .3773 .3750 .4691 .4684 .3740 .3731 A181SI-0607-04 iglidur A200 Chapter Page 433
®
3/8 15/32 3/8 .3773 .3750 .4691 .4684 .3740 .3731 A181SI-0607-06
3/8 15/32 1/2 .3773 .3750 .4691 .4684 .3740 .3731 A181SI-0607-08 d1 d2 b1 d1 3) Housing hole Shaft size Part No.
3/8 15/32 5/8 .3773 .3750 .4691 .4684 .3740 .3731 A181SI-0607-10 max. min. max. min. max. min.
3/8 15/32 3/4 .3773 .3750 .4691 .4684 .3740 .3731 A181SI-0607-12 1/8 1/4 1/4 .1280 .1262 .2515 .2510 .1250 .1241 ASI-0204-04
7/16 17/32 1/2 .4406 .4379 .5316 .5309 .4365 .4355 A181SI-0708-08 3/16 5/16 1/4 .1905 .1887 .3140 .3135 .1875 .1866 ASI-0305-04
7/16 17/32 3/4 .4406 .4379 .5316 .5309 .4365 .4355 A181SI-0708-12 1/4 3/8 1/4 .2539 .2516 .3765 .3760 .2500 .2491 ASI-0406-04
1/2 19/32 1/4 .5030 .5003 .5941 .5934 .4990 .4980 A181SI-0809-04 1/4 3/8 3/8 .2539 .2516 .3765 .3760 .2500 .2491 ASI-0406-06
1/2 19/32 3/8 .5030 .5003 .5941 .5934 .4990 .4980 A181SI-0809-06 1/4 3/8 1/2 .2539 .2516 .3765 .3760 .2500 .2491 ASI-0406-08
1/2 19/32 1/2 .5030 .5003 .5941 .5934 .4990 .4980 A181SI-0809-08 5/16 15/32 1/2 .3164 .3141 .4390 .4385 .3125 .3116 ASI-0507-08
1/2 19/32 5/8 .5030 .5003 .5941 .5934 .4990 .4980 A181SI-0809-10 3/8 1/2 1/4 .3789 .3766 .5015 .5010 .3750 .3741 ASI-0608-04
1/2 19/32 3/4 .5030 .5003 .5941 .5934 .4990 .4980 A181SI-0809-12 3/8 1/2 1/2 .3789 .3766 .5015 .5010 .3750 .3741 ASI-0608-08
1/2 19/32 1 .5030 .5003 .5941 .5934 .4990 .4980 A181SI-0809-16 1/2 5/8 1/2 .5047 .5020 .6260 .6250 .5000 .4990 ASI-0810-08
9/16 21/32 1/2 .5655 .5627 .6566 .6559 .5615 .5605 A181SI-0910-08 1/2 5/8 3/4 .5047 .5020 .6260 .6250 .5000 .4990 ASI-0810-12
9/16 21/32 5/8 .5655 .5627 .6566 .6559 .5615 .5605 A181SI-0910-10 5/8 13/16 5/16 .6297 .6270 .8135 .8125 .6250 .6240 ASI-1013-05
9/16 21/32 3/4 .5655 .5627 .6566 .6559 .5615 .5605 A181SI-0910-12 5/8 13/16 3/4 .6297 .6270 .8135 .8125 .6250 .6240 ASI-1013-12
5/8 23/32 1/2 .6280 .6253 .7192 .7184 .6240 .6230 A181SI-1011-08 3/4 1 3/4 .7559 .7525 1.0010 1.0000 .7500 .7490 ASI-1216-12
5/8 23/32 3/4 .6280 .6253 .7192 .7184 .6240 .6230 A181SI-1011-12 3/4 1 1 .7559 .7525 1.0010 1.0000 .7500 .7490 ASI-1216-16
5/8 23/32 1 .6280 .6253 .7192 .7184 .6240 .6230 A181SI-1011-16 7/8 1 1/8 1 .8809 .8775 1.1260 1.1250 .8750 .8740 ASI-1418-16
3/4 7/8 1/2 .7541 .7505 .8755 .8747 .7491 .7479 A181SI-1214-08 1 1 9/32 3/4 1.0059 1.0025 1.2510 1.2500 1.0000 .9990 ASI-1620-12
3/4 7/8 3/4 .7541 .7505 .8755 .8747 .7491 .7479 A181SI-1214-12 1 1 9/32 1 1.0059 1.0025 1.2510 1.2500 1.0000 .9990 ASI-1620-16
3/4 7/8 1 .7541 .7505 .8755 .8747 .7491 .7479 A181SI-1214-16 1 1/4 1 17/32 1 1.2600 1.2531 1.5005 1.4995 1.2500 1.249 ASI-2024-16
7/8 1 1/2 .8791 .8757 1.0005 .9997 .8741 .8729 A181SI-1416-08 1 1/2 1 3/4 1 1/2 1.5100 1.5032 1.7505 1.7495 1.5000 1.499 ASI-2428-24
3) After press-fit. Testing methods u Page 61 ASEAN 09/2023 ASEAN 09/2023 3) After press-fit. Testing methods u Page 61
1100 Service life calculation, configuration and more u www.igus-asean.com 3D CAD files, prices and delivery time online u www.igus-asean.com 1101
