iglidur Imperial product range | iglidur | Flanged bearings Imperial product range | iglidur | Flanged bearings iglidur
®
®
form F form F
d1 d2 b1 d3 b2 d1 3) Housing hole Shaft size Part No. d1 d2 b1 d3 b2 d1 3) Housing hole Shaft size Part No.
h13 max. min. max. min. max. min. h13 max. min. max. min. max. min.
1/2 19/32 1 .8750 .0460 .5030 .5003 .5941 .5934 .4990 .4980 J3FI-0809-16 3/4 7/8 1 1.1250 .0620 .7532 .7499 .8755 .8747 .7491 .7479 J350FI-1214-16
5/8 23/32 1/2 .9370 .0460 .6280 .6253 .7192 .7184 .6240 .6230 J3FI-1011-08 7/8 1 1/2 1.2500 .0620 .8782 .8749 1.0005 .9997 .8741 .8729 J350FI-1416-08
5/8 23/32 3/4 .9370 .0460 .6280 .6253 .7192 .7184 .6240 .6230 J3FI-1011-12 7/8 1 3/4 1.2500 .0620 .8782 .8749 1.0005 .9997 .8741 .8729 J350FI-1416-12
5/8 23/32 1 .9370 .0460 .6280 .6253 .7192 .7184 .6240 .6230 J3FI-1011-16 7/8 1 1 1.2500 .0620 .8782 .8749 1.0005 .9997 .8741 .8729 J350FI-1416-16
3/4 7/8 1/2 1.1250 .0620 .7541 .7505 .8755 .8747 .7491 .7479 J3FI-1214-08 1 1 1/8 1/2 1.3750 .0620 1.0032 .9999 1.1255 1.1247 .9991 .9979 J350FI-1618-08
3/4 7/8 3/4 1.1250 .0620 .7541 .7505 .8755 .8747 .7491 .7479 J3FI-1214-12 1 1 1/8 3/4 1.3750 .0620 1.0032 .9999 1.1255 1.1247 .9991 .9979 J350FI-1618-12
3/4 7/8 1 1.1250 .0620 .7541 .7505 .8755 .8747 .7491 .7479 J3FI-1214-16 1 1 1/8 1 1.3750 .0620 1.0032 .9999 1.1255 1.1247 .9991 .9979 J350FI-1618-16
7/8 1 1/2 1.2500 .0620 .8791 .8757 1.0005 .9997 .8741 .8729 J3FI-1416-08 1 1/4 1 13/32 1 1.6870 .0780 1.2537 1.2498 1.4068 1.4058 1.2488 1.2472 J350FI-2022-16
7/8 1 3/4 1.2500 .0620 .8791 .8757 1.0005 .9997 .8741 .8729 J3FI-1416-12 1 1/4 1 13/32 1 1/4 1.6870 .0780 1.2537 1.2498 1.4068 1.4058 1.2488 1.2472 J350FI-2022-20
7/8 1 1 1.2500 .0620 .8791 .8757 1.0005 .9997 .8741 .8729 J3FI-1416-16 1 1/2 1 21/32 1 2.0000 .0780 1.5037 1.4998 1.6568 1.6558 1.4988 1.4972 J350FI-2426-16
1 1 1/8 1/2 1.3750 .0620 1.0041 1.0007 1.1255 1.1247 .9991 .9979 J3FI-1618-08 1 1/2 1 21/32 1 1/2 2.0000 .0780 1.5037 1.4998 1.6568 1.6558 1.4988 1.4972 J350FI-2426-24
1 1 1/8 3/4 1.3750 .0620 1.0041 1.0007 1.1255 1.1247 .9991 .9979 J3FI-1618-12 1 3/4 1 15/16 2 2.3750 .0930 1.7536 1.7497 1.9381 1.9371 1.7487 1.7471 J350FI-2831-32
1 1 1/8 1 1.3750 .0620 1.0041 1.0007 1.1255 1.1247 .9991 .9979 J3FI-1618-16 2 2 3/16 2 2.6250 .0930 2.0040 1.9993 2.1883 2.1871 1.9981 1.9969 J350FI-3235-32
1 1/4 1 13/32 1 1.6870 .0780 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 J3FI-2022-16
1 1/4 1 13/32 1 1/4 1.6870 .0780 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 J3FI-2022-20 iglidur M250 Chapter Page 111
®
1 1/2 1 21/32 1 2.0000 .0780 1.5048 1.5008 1.6568 1.6558 1.4988 1.4972 J3FI-2426-16
1 1/2 1 21/32 1 1/2 2.0000 .0780 1.5048 1.5008 1.6568 1.6558 1.4988 1.4972 J3FI-2426-24 d1 d2 b1 d3 b2 d1 3) Housing hole Shaft size Part No.
1 3/4 1 15/16 2 2.3750 .0930 1.7547 1.7507 1.9381 1.9371 1.7487 1.7471 J3FI-2831-32 h13 max. min. max. min. max. min.
2 2 3/16 2 2.6250 .0930 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 J3FI-3235-32 1/8 3/16 1/8 .3125 .0320 .1280 .1262 .1885 .1880 .1250 .1241 MFI-0203-02
1/8 3/16 1/4 .3125 .0320 .1280 .1262 .1885 .1880 .1250 .1241 MFI-0203-04
iglidur J350 Chapter Page 203 1/8 1/4 1/8 .3600 .0470 .1280 .1262 .2515 .2510 .1250 .1241 MFI-0204-02
®
1/8 1/4 3/16 .3600 .0470 .1280 .1262 .2515 .2510 .1250 .1241 MFI-0204-03
d1 d2 b1 d3 b2 d1 3) Housing hole Shaft size Part No. 1/8 1/4 1/4 .3600 .0470 .1280 .1262 .2515 .2510 .1250 .1241 MFI-0204-04
h13 max. min. max. min. max. min. 1/8 1/4 3/8 .3600 .0470 .1280 .1262 .2515 .2510 .1250 .1241 MFI-0204-06
1/8 3/16 3/16 .3120 .0320 .1266 .1247 .1878 .1873 .1243 .1236 J350FI-0203-03 1/8 1/4 3/4 .3600 .0470 .1280 .1262 .2515 .2510 .1250 .1241 MFI-0204-12
3/16 1/4 1/4 .3750 .0320 .1888 .1869 .2503 .2497 .1865 .1858 J350FI-0304-04 3/16 1/4 1/4 .3750 .0320 .1905 .1887 .2515 .2510 .1875 .1866 MFI-0304-04
1/4 5/16 3/8 .5000 .0320 .2518 .2495 .3128 .3122 .2490 .2481 J350FI-0405-06 3/16 1/4 3/8 .3750 .0320 .1905 .1887 .2515 .2510 .1875 .1866 MFI-0304-06
1/4 5/16 1/2 .5000 .0320 .2518 .2495 .3128 .3122 .2490 .2481 J350FI-0405-08 3/16 1/4 1/2 .3750 .0320 .1905 .1887 .2515 .2510 .1875 .1866 MFI-0304-08
5/16 3/8 1/4 .5620 .0320 .3143 .3120 .3753 .3747 .3115 .3106 J350FI-0506-04 3/16 5/16 3/16 .3700 .0470 .1905 .1887 .3140 .3135 .1875 .1866 MFI-0305-03
5/16 3/8 3/8 .5620 .0320 .3143 .3120 .3753 .3747 .3115 .3106 J350FI-0506-06 3/16 5/16 1/4 .3700 .0470 .1905 .1887 .3140 .3135 .1875 .1866 MFI-0305-04
5/16 3/8 1/2 .5620 .0320 .3143 .3120 .3753 .3747 .3115 .3106 J350FI-0506-08 3/16 5/16 5/16 .3700 .0470 .1905 .1887 .3140 .3135 .1875 .1866 MFI-0305-05
3/8 15/32 1/4 .6870 .0460 .3768 .3745 .4691 .4684 .3740 .3731 J350FI-0607-04 3/16 5/16 3/8 .3700 .0470 .1905 .1887 .3140 .3135 .1875 .1866 MFI-0305-06
3/8 15/32 3/8 .6870 .0460 .3768 .3745 .4691 .4684 .3740 .3731 J350FI-0607-06 3/16 5/16 1/2 .3700 .0470 .1905 .1887 .3140 .3135 .1875 .1866 MFI-0305-08
3/8 15/32 1/2 .6870 .0460 .3768 .3745 .4691 .4684 .3740 .3731 J350FI-0607-08 1/4 5/16 3/16 .4375 .0470 .2539 .2516 .3140 .3135 .2500 .2491 MFI-0405-03
3/8 15/32 3/4 .6870 .0460 .3768 .3745 .4691 .4684 .3740 .3731 J350FI-0607-12 1/4 5/16 1/4 .4375 .0320 .2539 .2516 .3140 .3135 .2500 .2491 MFI-0405-04
7/16 17/32 1/2 .7500 .0460 .4399 .4371 .5316 .5309 .4365 .4355 J350FI-0708-08 1/4 5/16 3/8 .4375 .0320 .2539 .2516 .3140 .3135 .2500 .2491 MFI-0405-06
1/2 19/32 1/4 .8750 .0460 .5024 .4996 .5941 .5934 .4990 .4980 J350FI-0809-04 1/4 5/16 7/16 .4375 .0470 .2539 .2516 .3140 .3135 .2500 .2491 MFI-0405-07
1/2 19/32 3/8 .8750 .0460 .5024 .4996 .5941 .5934 .4990 .4980 J350FI-0809-06 1/4 5/16 1/2 .4375 .0320 .2539 .2516 .3140 .3135 .2500 .2491 MFI-0405-08
1/2 19/32 1/2 .8750 .0460 .5024 .4996 .5941 .5934 .4990 .4980 J350FI-0809-08 1/4 5/16 3/4 .4375 .0470 .2539 .2516 .3140 .3135 .2500 .2491 MFI-0405-12
1/2 19/32 3/4 .8750 .0460 .5024 .4996 .5941 .5934 .4990 .4980 J350FI-0809-12 1/4 3/8 1/8 .5600 .0470 .2539 .2516 .3765 .3760 .2500 .2491 MFI-0406-02
1/2 19/32 1 .8750 .0460 .5024 .4996 .5941 .5934 .4990 .4980 J350FI-0809-16 1/4 3/8 3/16 .5600 .0470 .2539 .2516 .3765 .3760 .2500 .2491 MFI-0406-03
5/8 23/32 1/2 .9370 .0460 .6274 .6246 .7192 .7184 .6240 .6230 J350FI-1011-08 1/4 3/8 1/4 .5600 .0470 .2539 .2516 .3765 .3760 .2500 .2491 MFI-0406-04
5/8 23/32 3/4 .9370 .0460 .6274 .6246 .7192 .7184 .6240 .6230 J350FI-1011-12 1/4 3/8 3/8 .5600 .0470 .2539 .2516 .3765 .3760 .2500 .2491 MFI-0406-06
5/8 23/32 1 .9370 .0460 .6274 .6246 .7192 .7184 .6240 .6230 J350FI-1011-16 1/4 3/8 1/2 .5600 .0470 .2539 .2516 .3765 .3760 .2500 .2491 MFI-0406-08
3/4 7/8 1/2 1.1250 .0620 .7532 .7499 .8755 .8747 .7491 .7479 J350FI-1214-08 1/4 3/8 5/8 .5600 .0470 .2539 .2516 .3765 .3760 .2500 .2491 MFI-0406-10
3/4 7/8 3/4 1.1250 .0620 .7532 .7499 .8755 .8747 .7491 .7479 J350FI-1214-12 1/4 3/8 3/4 .5600 .0470 .2539 .2516 .3765 .3760 .2500 .2491 MFI-0406-12
3) After press-fit. Testing methods u Page 61 ASEAN 09/2023 ASEAN 09/2023 3) After press-fit. Testing methods u Page 61
