P. 1144
Inch Inch
®
®
iglidur Imperial product range | iglidur | Flanged bearings Imperial product range | iglidur | Flanged bearings iglidur
®
®
form F form F
d1 d2 b1 d3 b2 d1 3) Housing hole Shaft size Part No. d1 d2 b1 d3 b2 d1 3) Housing hole Shaft size Part No.
h13 max. min. max. min. max. min. h13 max. min. max. min. max. min.
7/8 1 3/4 1.2500 .0620 .8791 .8757 1.0005 .9997 .8741 .8729 QFI-1416-12 1 1 1/8 1 1.3750 .0620 1.0041 1.0007 1.1255 1.1247 .9991 .9979 Q2FI-1618-16
7/8 1 1 1.2500 .0620 .8791 .8757 1.0005 .9997 .8741 .8729 QFI-1416-16 1 1/4 1 13/32 1 1.6870 .0780 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 Q2FI-2022-16
1 1 1/8 1/2 1.3750 .0620 1.0041 1.0007 1.1255 1.1247 .9991 .9979 QFI-1618-08 1 1/4 1 13/32 1 1/4 1.6870 .0780 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 Q2FI-2022-20
1 1 1/8 1 1.3750 .0620 1.0041 1.0007 1.1255 1.1247 .9991 .9979 QFI-1618-16 1 1/2 1 21/32 1 2.0000 .0780 1.5048 1.5008 1.6568 1.6558 1.4988 1.4972 Q2FI-2426-16
1 1 1/8 1 1/2 1.3750 .0620 1.0041 1.0007 1.1255 1.1247 .9991 .9979 QFI-1618-24 1 1/2 1 21/32 1 1/2 2.0000 .0780 1.5048 1.5008 1.6568 1.6558 1.4988 1.4972 Q2FI-2426-24
1 1/8 1 9/32 3/4 1.5620 .0780 1.1288 1.1254 1.2818 1.2808 1.1238 1.1226 QFI-1820-12 1 3/4 1 15/16 2 2.3750 .0930 1.7547 1.7507 1.9381 1.9371 1.7487 1.7471 Q2FI-2831-32
1 1/8 1 9/32 1 1/2 1.5620 .0780 1.1288 1.1254 1.2818 1.2808 1.1238 1.1226 QFI-1820-24 2 2 3/16 2 2.6250 .0930 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 Q2FI-3235-32
1 1/4 1 13/32 1 1/4 1.6870 .0780 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 QFI-2022-20
1 1/4 1 13/32 1 1/2 1.6870 .0780 1.2548 1.2508 1.4068 1.4058 1.2488 1.2472 QFI-2022-24 iglidur W300 Chapter Page 175
®
1 1/2 1 21/32 1 1/2 2.0000 .0780 1.5048 1.5008 1.6568 1.6558 1.4988 1.4972 QFI-2426-24
1 3/4 1 15/16 2 2.3750 .0930 1.7547 1.7507 1.9381 1.9371 1.7487 1.7471 QFI-2831-32 d1 d2 b1 d3 b2 d1 3) Housing hole Shaft size Part No.
2 2 3/16 2 2.6250 .0930 2.0057 2.0011 2.1883 2.1871 1.9981 1.9969 QFI-3235-32 h13 max. min. max. min. max. min.
2 1/4 2 7/16 2 2.7500 .0930 2.2577 2.2531 2.4377 2.4365 2.2507 2.2489 QFI-3639-32 1/8 3/16 3/16 .3120 .0320 .1269 .1251 .1878 .1873 .1243 .1236 WFI-0203-03
1/8 3/16 1/4 .3120 .0320 .1269 .1251 .1878 .1873 .1243 .1236 WFI-0203-04
iglidur Q2 Chapter Page 477 1/8 3/16 3/8 .3120 .0320 .1269 .1251 .1878 .1873 .1243 .1236 WFI-0203-06
®
3/16 1/4 1/8 .3750 .0320 .1892 .1873 .2503 .2497 .1865 .1858 WFI-0304-02
d1 d2 b1 d3 b2 d1 3) Housing hole Shaft size Part No. 3/16 1/4 1/4 .3750 .0320 .1892 .1873 .2503 .2497 .1865 .1858 WFI-0304-04
h13 max. min. max. min. max. min. 3/16 1/4 3/8 .3750 .0320 .1892 .1873 .2503 .2497 .1865 .1858 WFI-0304-06
1/8 3/16 3/16 .3120 .0320 .1269 .1251 .1878 .1873 .1243 .1236 Q2FI-0203-03 3/16 1/4 1/2 .3750 .0320 .1892 .1873 .2503 .2497 .1865 .1858 WFI-0304-08
3/16 1/4 1/4 .3750 .0320 .1892 .1873 .2503 .2497 .1865 .1858 Q2FI-0304-04 1/4 5/16 1/4 .5000 .0320 .2521 .2498 .3128 .3122 .2490 .2481 WFI-0405-04
1/4 5/16 3/8 .5000 .0320 .2521 .2498 .3128 .3122 .2490 .2481 Q2FI-0405-06 1/4 5/16 5/16 .5000 .0320 .2521 .2498 .3128 .3122 .2490 .2481 WFI-0405-05
1/4 5/16 1/2 .5000 .0320 .2521 .2498 .3128 .3122 .2490 .2481 Q2FI-0405-08 1/4 5/16 3/8 .5000 .0320 .2521 .2498 .3128 .3122 .2490 .2481 WFI-0405-06
5/16 3/8 1/4 .5620 .0320 .3148 .3125 .3753 .3747 .3115 .3106 Q2FI-0506-04 1/4 5/16 1/2 .5000 .0320 .2521 .2498 .3128 .3122 .2490 .2481 WFI-0405-08
5/16 3/8 3/8 .5620 .0320 .3148 .3125 .3753 .3747 .3115 .3106 Q2FI-0506-06 1/4 5/16 3/4 .5000 .0320 .2521 .2498 .3128 .3122 .2490 .2481 WFI-0405-12
5/16 3/8 1/2 .5620 .0320 .3148 .3125 .3753 .3747 .3115 .3106 Q2FI-0506-08 5/16 3/8 1/4 .5620 .0320 .3148 .3125 .3753 .3747 .3115 .3106 WFI-0506-04
3/8 15/32 1/4 .6870 .0460 .3773 .3750 .4691 .4684 .3740 .3731 Q2FI-0607-04 5/16 3/8 3/8 .5620 .0320 .3148 .3125 .3753 .3747 .3115 .3106 WFI-0506-06
3/8 15/32 3/8 .6870 .0460 .3773 .3750 .4691 .4684 .3740 .3731 Q2FI-0607-06 5/16 3/8 1/2 .5620 .0320 .3148 .3125 .3753 .3747 .3115 .3106 WFI-0506-08
3/8 15/32 1/2 .6870 .0460 .3773 .3750 .4691 .4684 .3740 .3731 Q2FI-0607-08 5/16 3/8 3/4 .5620 .0320 .3148 .3125 .3753 .3747 .3115 .3106 WFI-0506-12
3/8 15/32 3/4 .6870 .0460 .3773 .3750 .4691 .4684 .3740 .3731 Q2FI-0607-12 3/8 15/32 1/4 .6870 .0460 .3773 .3750 .4691 .4684 .3740 .3731 WFI-0607-04
7/16 17/32 1/2 .7500 .0460 .4406 .4379 .5316 .5309 .4365 .4355 Q2FI-0708-08 3/8 15/32 3/8 .6870 .0460 .3773 .3750 .4691 .4684 .3740 .3731 WFI-0607-06
1/2 19/32 1/4 .8750 .0460 .5030 .5003 .5941 .5934 .4990 .4980 Q2FI-0809-04 3/8 15/32 1/2 .6870 .0460 .3773 .3750 .4691 .4684 .3740 .3731 WFI-0607-08
1/2 19/32 3/8 .8750 .0460 .5030 .5003 .5941 .5934 .4990 .4980 Q2FI-0809-06 3/8 15/32 3/4 .6870 .0460 .3773 .3750 .4691 .4684 .3740 .3731 WFI-0607-12
1/2 19/32 1/2 .8750 .0460 .5030 .5003 .5941 .5934 .4990 .4980 Q2FI-0809-08 7/16 17/32 1/2 .7500 .0460 .4406 .4379 .5316 .5309 .4365 .4355 WFI-0708-08
1/2 19/32 3/4 .8750 .0460 .5030 .5003 .5941 .5934 .4990 .4980 Q2FI-0809-12 1/2 19/32 1/4 .8750 .0460 .5030 .5003 .5941 .5934 .4990 .4980 WFI-0809-04
1/2 19/32 1 .8750 .0460 .5030 .5003 .5941 .5934 .4990 .4980 Q2FI-0809-16 1/2 19/32 3/8 .8750 .0460 .5030 .5003 .5941 .5934 .4990 .4980 WFI-0809-06
5/8 23/32 1/2 .9370 .0460 .6280 .6253 .7192 .7184 .6240 .6230 Q2FI-1011-08 1/2 19/32 1/2 .8750 .0460 .5030 .5003 .5941 .5934 .4990 .4980 WFI-0809-08
5/8 23/32 3/4 .9370 .0460 .6280 .6253 .7192 .7184 .6240 .6230 Q2FI-1011-12 1/2 19/32 3/4 .8750 .0460 .5030 .5003 .5941 .5934 .4990 .4980 WFI-0809-12
5/8 23/32 1 .9370 .0460 .6280 .6253 .7192 .7184 .6240 .6230 Q2FI-1011-16 1/2 19/32 1 .8750 .0460 .5030 .5003 .5941 .5934 .4990 .4980 WFI-0809-16
3/4 7/8 1/2 1.1250 .0620 .7541 .7505 .8755 .8747 .7491 .7479 Q2FI-1214-08 5/8 23/32 9/32 .9370 .0460 .6280 .6253 .7192 .7184 .6240 .6230 WFI-1011-045
3/4 7/8 3/4 1.1250 .0620 .7541 .7505 .8755 .8747 .7491 .7479 Q2FI-1214-12 5/8 23/32 1/2 .9370 .0460 .6280 .6253 .7192 .7184 .6240 .6230 WFI-1011-08
3/4 7/8 1 1.1250 .0620 .7541 .7505 .8755 .8747 .7491 .7479 Q2FI-1214-16 5/8 23/32 3/4 .9370 .0460 .6280 .6253 .7192 .7184 .6240 .6230 WFI-1011-12
7/8 1 1/2 1.2500 .0620 .8791 .8757 1.0005 .9997 .8741 .8729 Q2FI-1416-08 5/8 23/32 1 .9370 .0460 .6280 .6253 .7192 .7184 .6240 .6230 WFI-1011-16
7/8 1 3/4 1.2500 .0620 .8791 .8757 1.0005 .9997 .8741 .8729 Q2FI-1416-12 5/8 23/32 1 1/2 .9370 .0460 .6280 .6253 .7192 .7184 .6240 .6230 WFI-1011-24
7/8 1 1 1.2500 .0620 .8791 .8757 1.0005 .9997 .8741 .8729 Q2FI-1416-16 3/4 7/8 1/2 1.1250 .0620 .7541 .7507 .8755 .8747 .7491 .7479 WFI-1214-08
1 1 1/8 1/2 1.3750 .0620 1.0041 1.0007 1.1255 1.1247 .9991 .9979 Q2FI-1618-08 3/4 7/8 5/8 1.1250 .0620 .7541 .7507 .8755 .8747 .7491 .7479 WFI-1214-10
1 1 1/8 3/4 1.3750 .0620 1.0041 1.0007 1.1255 1.1247 .9991 .9979 Q2FI-1618-12 3/4 7/8 3/4 1.1250 .0620 .7541 .7507 .8755 .8747 .7491 .7479 WFI-1214-12
3) After press-fit. Testing methods u Page 61 ASEAN 09/2023 ASEAN 09/2023 3) After press-fit. Testing methods u Page 61
1142 Service life calculation, configuration and more u www.igus-asean.com 3D CAD files, prices and delivery time online u www.igus-asean.com 1143
