iglidur iglidur
®
®
®
®
tribo iglidur tribo 3D printing | 3D printing service iglidur tribo 3D printing | 3D printing service tribo
3D printing 3D printing
Individual wear-resistant parts in 3 days - order online
Wear-resistant parts from the 3D printing SLS can also be used to make wear- Dimensional stability and size of installation
service: online and extremely fast resistant parts space
Printed parts extremely wear-resistant- as prototype or in The 3D printing service is also available with all of our SLS The precision of the printed parts in the case of the iglidur
®
small series. Simply upload your required part, determine powders. Laser sintering (SLS) is used to make parts of tribofilaments is ±0.2mm (up to an edge length of 50mm,
®
the price and order online (or ask for a quotation). Thanks these materials. With this method even more plain bearing above this ±0.4%). In the case of parts made using the
to the iglidur 3D printing service, from now on 2 quick and applications are therefore possible with 3D-printed parts, laser sintering process the precision is ±0.1mm (up to an
®
easy steps will complete your customised component made strength and precision are considerably greater and the edge length of 50mm, above this ±0.2 %).
of lubrication-free and abrasion-resistant iglidur plastics. price per component is lower. The space used for processing the iglidur tribofilaments
®
®
®
The service life of the 3D printed components is comparable measures 135x145x200mm. In the case of laser sintering
to igus injection moulded parts. In the online 3D printing Additional laser sintering services the space used measures 170x220x300mm. The following
®
calculation, you can not only receive 3D printing, but also In the 3D printing service, more services for laser sintering applies to both processes: larger parts may have to be
analyse feasibility and prices of injection-moulded parts materials can now be selected and their prices easily made of several pieces.
made with 3D-printed moulds (print2mold). Material selection defined.
● Black colouring for visible parts Large-format 3D printing
Go to www.igus-asean.com/idd and upload the ● Polish surfaces using vibratory finishing or chemical Up to 3 metres-large components made of iglidur i150
®
3D model in the STEP format. The manufacturability polishing and iglidur i151 in a 3D printing process. The space of the
®
(wall thickness and component size) is analysed large-format printer measures 1,000x500x500mm. Larger
automatically New: Multi-material print (FDM/FFF) parts may have to be made of several pieces
Select material and quantity and order the component Workpieces with up to four components made from proven
or ask for a quotation. tribofilaments and other plastics. In order to ensure that the 3D-printed components function
®
u Your individual wear-resistant part will be shipped One possible combination would be intelligent bearings for correctly, the following should be included in the 3D model:
in 72 hours predictive maintenance: with a fibre-reinforced housing, ● The 3D model should be at the centre of tolerance;
tribofilament and integrated conductor tracks to warn of e.g. for a tolerance of 16mm to 0.2mm, the 3D model
®
Delivery time
72hrs bearing wear. should correspond to 15.9mm to
● In the case of clearance fits, a play of approx. 0.1mm
should be planned
● Minimum wall thickness: SLS 0.7mm, FDM/FFF 1mm
New: Calculate the service life of sliding
surfaces Wall thickness analyses
With the new service life calculator, you can determine the 900
service life of individual components. Simply click on sliding 800
surface and enter the parameters. 700
600
500
Try it out now: New: Digital Light Processing (DLP) 400
u www.igus-asean.com/idd
In the DLP 3D printing service, igus processes its own 300
®
iglidur i3000 resin in the classic DLP process with a Wear rate [µm/km] 200
®
high resolution that allows precision components to be 100
manufactured. In addition, the UV wavelength of 385nm can 0 ABS PA12 iglidur iglidur iglidur iglidur
®
®
®
®
reduce excessive curing and ensure a more precise shape. (FDM) (SLS) i180 J260 i3 W300
(FDM) (FDM) (SLS) moulded
Wear, rotating p =20MPa; v = 0.01m/s, 304 stainless
steel
Shopping cart

ASEAN 09/2023 ASEAN 09/2023

826 More information u www.igus-asean.com/3dprintservice Try it out now u www.igus-asean.com/idd 827
