drylin R drylin R
®
®
®
®
shaft drylin R liners | Product range drylin R liners | Product range shaft
guides guides
Long, closed design for shafts - Long, open design for supported shafts -
made from iglidur J (the all-rounder) made from iglidur J (the all-rounder)
®
®
Order key Order key
d2 d2
Type Size Type Size
Y Y 2:1
Y Y 2:1
Z Z

t
b1 r d1 b1 r t
d1
iglidur ® J Liner Metric Standard Inner Ø d1 iglidur ® J Liner Metric Open Standard Inner Ø d1

®
®
The all-rounder for all shaft surfaces 78) According to igus testing method u Page 260 The all-rounder for all shaft surfaces 78) According to igus testing method u Page 260
in indoor and outdoor applications Please note: Installation instructions u Page 187 in indoor and outdoor applications Please note: Installation instructions u Page 187
Min. -50°C Min. -50°C
Max. +90°C Max. +90°C
Dimensions [mm] Dimensions [mm]

d1 d1 tolerance 78) d2 b1 r t Z Weight Part No. d1 d1 tolerance 78) d2 b1 r t Z Weight Part No.
[g] [g]
[g]
10 +0.030 +0.070 12 28 3.0 0.8 2.5 1.10 JUM-01-10 10 +0.030 +0.070 12 28 3.0 0.8 2.5 0.90 JUMO-01-10
12 +0.030 +0.070 14 31 3.0 0.8 3.0 1.50 JUM-01-12 12 +0.030 +0.070 14 31 3.0 0.8 3.0 1.16 JUMO-01-12
16 +0.030 +0.070 18 35 3.5 0.8 3.5 2.20 JUM-01-16 16 +0.030 +0.070 18 35 3.5 0.8 3.5 1.71 JUMO-01-16
20 +0.030 +0.070 23 44 5.0 0.8 3.5 4.90 JUM-01-20 20 +0.030 +0.070 23 44 5.0 0.8 3.5 4.16 JUMO-01-20
25 +0.030 +0.070 28 57 5.0 0.8 4.0 8.23 JUM-01-25 25 +0.030 +0.070 28 57 5.0 0.8 4.0 6.97 JUMO-01-25
30 +0.040 +0.085 34 67 5.0 0.8 4.0 14.95 JUM-01-30 30 +0.040 +0.085 34 67 5.0 0.8 4.0 12.38 JUMO-01-30
35 +0.040 +0.085 39 69 5.0 0.8 4.0 18.20 JUM-01-35 40 +0.040 +0.085 44 79 6.0 1.3 5.0 20.18 JUMO-01-40
40 +0.040 +0.085 44 79 6.0 1.3 5.0 23.16 JUM-01-40 50 +0.050 +0.150 55 99 7.0 1.3 6.0 38.60 JUMO-01-50
50 +0.050 +0.150 55 99 7.0 1.3 6.0 45.35 JUM-01-50 60 +0.050 +0.150 65 124 8.0 2.0 6.5 60.10 JUMO-01-60 79)
60 +0.050 +0.150 65 124 8.0 2.0 6.5 70.00 JUM-01-60 79)

Housing hole for JUM-01 | Dimensions [mm] Housing hole for JUMO-01 | Dimensions [mm]
B B
Shaft di B r t f Z Part No. B / 2 Shaft di B W r t f Z Part No. B / 2
Ø H7 h10 +0.05 +0.1 +0.5 +0.2 Ø Z Ø H7 h10 +0.5 +0.05 +0.1 +0.2 r
10 12 29 3.0 1.0 1.0 2.6 JUM-01-10 f 10 12 29 7.3 3.0 1.0 1.0 2.6 JUMO-01-10
12 14 32 3.0 1.0 1.5 3.1 JUM-01-12 12 14 32 9.0 3.0 1.0 1.5 3.1 JUMO-01-12 t
16 18 36 3.5 1.0 1.7 3.6 JUM-01-16 16 18 36 11.6 3.5 1.0 1.7 3.6 JUMO-01-16 Ø di
20 23 45 5.0 1.0 2.0 3.6 JUM-01-20 Ø di 20 23 45 12.0 5.0 1.0 2.0 3.6 JUMO-01-20
25 28 58 5.0 1.0 2.0 4.1 JUM-01-25 t 25 28 58 14.5 5.0 1.0 2.0 4.1 JUMO-01-25
30 34 68 5.0 1.0 2.0 4.1 JUM-01-30 30 34 68 16.6 5.0 1.0 2.0 4.1 JUMO-01-30
35 39 70 5.0 1.0 2.0 4.1 JUM-01-35 40 44 80 21.0 6.0 1.5 2.5 5.1 JUMO-01-40 Ø Z
W
40 44 80 6.0 1.5 2.5 5.1 JUM-01-40 r 50 55 100 25.5 7.0 1.5 2.5 6.1 JUMO-01-50
50 55 100 7.0 1.5 2.5 6.1 JUM-01-50 60 65 125 27.2 8.0 2.5 3.0 6.5 JUMO-01-60 79)
60 65 125 8.0 2.5 3.0 6.5 JUM-01-60 79) 79) In two parts
79) In two parts

Can be combined with: Can be combined with:
f
Imperial dimensions Imperial dimensions
u Page 746 u Page 746
RJUM-01/-03 RJUM-06/-06-LL FJUM-01/-02 ASEAN 09/2023 ASEAN 09/2023 OJUM-01/-03 OJUM-06/-06-LL
TJUM-01/-03
188 Online tools and more information u www.igus-asean.com/drylinR 3D CAD files, prices and delivery time online u www.igus-asean.com/drylinR 189
