Page 196 - IGUS Linear

drylin R drylin R
®
®
®
®
shaft drylin R liners | Product range drylin R liners | Product range shaft
guides guides
Long, open design for supported shafts - Long, closed design for shafts -
made from iglidur J200 (the specialist) made from iglidur E7 (the endurance runner)
®
®
Order key Order key
d2 d2
Type Size Type Size
Y Y 2:1
Y Y 2:1
Z Z

t
b1 r t b1 r
d1 d1
iglidur ® J200 Liner Metric Open Standard Inner Ø d1 iglidur ® E7 Liner Metric Standard Inner Ø d1

®
The "specialist" with the best running performance on 78) According to igus testing method u Page 260 The "endurance runner" up to 8 times longer service 78) According to igus testing method u Page 260
®
aluminium Please note: Installation instructions u Page 187 life on steel shafts Please note: Installation instructions u Page 187
Min. -50°C Min. -50°C
Max. +90°C Max. +70°C
Dimensions [mm] Dimensions [mm]

d1 d1 tolerance 78) d2 b1 r t Z Weight Part No. d1 d1 tolerance 78) d2 b1 r t Z Weight Part No.
[g] [g]
10 +0.030 +0.070 12 28 3.0 0.8 2.5 1.04 J200UMO-01-10 10 +0.030 +0.070 12 28 3.0 0.8 2.5 0.73 E7UM-01-10
12 +0.030 +0.070 14 31 3.0 0.8 3.0 1.34 J200UMO-01-12 12 +0.030 +0.070 14 31 3.0 0.8 3.0 1.01 E7UM-01-12
16 +0.030 +0.070 18 35 3.5 0.8 3.5 1.98 J200UMO-01-16 16 +0.030 +0.070 18 35 3.5 0.8 3.5 1.45 E7UM-01-16
20 +0.030 +0.070 23 44 5.0 0.8 3.5 4.80 J200UMO-01-20 20 +0.030 +0.070 23 44 5.0 0.8 3.5 3.25 E7UM-01-20
25 +0.030 +0.070 28 57 5.0 0.8 4.0 8.05 J200UMO-01-25 25 +0.030 +0.070 28 57 5.0 0.8 4.0 5.44 E7UM-01-25
30 +0.040 +0.085 34 67 5.0 0.8 4.0 14.30 J200UMO-01-30 30 +0.040 +0.085 34 67 5.0 0.8 4.0 9.88 E7UM-01-30
40 +0.040 +0.085 44 79 6.0 1.3 5.0 23.31 J200UMO-01-40 40 +0.040 +0.085 44 79 6.0 1.3 5.0 17.30 E7UM-01-40
50 +0.050 +0.150 55 99 7.0 1.3 6.0 36.30 E7UM-01-50 79)
60 +0.050 +0.150 65 124 8.0 2.5 6.5 54.80 E7UM-01-60 79)

Housing hole for J200UMO-01 | Dimensions [mm] Housing hole for E7UM-01 | Dimensions [mm]
B B
Shaft di B W r t f Z Part No. B / 2 Shaft di B r t f Z Part No. B / 2
Ø H7 h10 +0.5 +0.05 +0.1 +0.2 r Ø H7 h10 +0.5 +0.05 +0.1 +0.2 Ø Z
10 12 29 7.3 3.0 1.0 1.0 2.6 J200UMO-01-10 10 12 29 3.0 1.0 1.0 2.6 E7UM-01-10 f
12 14 32 9.0 3.0 1.0 1.5 3.1 J200UMO-01-12 t 12 14 32 3.0 1.0 1.5 3.1 E7UM-01-12
16 18 36 11.6 3.5 1.0 1.7 3.6 J200UMO-01-16 Ø di 16 18 36 3.5 1.0 1.7 3.6 E7UM-01-16
20 23 45 12.0 5.0 1.0 2.0 3.6 J200UMO-01-20 20 23 45 5.0 1.0 2.0 3.6 E7UM-01-20 Ø di
25 28 58 14.5 5.0 1.0 2.0 4.1 J200UMO-01-25 25 28 58 5.0 1.0 2.0 4.1 E7UM-01-25 t
30 34 68 16.6 5.0 1.0 2.0 4.1 J200UMO-01-30 30 34 68 5.0 1.0 2.0 4.1 E7UM-01-30
40 44 80 21.0 6.0 1.5 2.5 5.1 J200UMO-01-40 Ø Z 40 44 80 6.0 1.5 2.5 5.1 E7UM-01-40
50 55 100 7.0 1.5 2.5 6.1 E7UM-01-50 79) r
W
60 65 125 8.0 2.5 3.0 6.5 E7UM-01-60 79)
79) In two parts

Can be combined with: Can be combined with:
Imperial dimensions
ASEAN 09/2023 ASEAN 09/2023 TJUM-01/-03
f u Page 746
OJUM-01/-03 OJUM-06/-06-LL RJUM-01/-03 RJUM-01-ES RJUM-06/-06-LL FJUM-01/-02

194 Online tools and more information u www.igus-asean.com/drylinR 3D CAD files, prices and delivery time online u www.igus-asean.com/drylinR 195
