drylin R drylin R
®
®
®
®
shaft drylin R liners | Product range drylin R liners | Product range shaft
guides guides
Long, closed design, precise for shafts - Long, open design, precise for supported shafts -
made from iglidur J (the all-rounder) made from iglidur J (the all-rounder)
®
®
Order key Order key
d2 d2
Type Size Type Size
Y Y Y 2:1

Z Z
b1 r t
t
b1 r d1 d1
iglidur ® J Liner Metric Precision Inner Ø d1 iglidur ® J Liner Metric Open Precision Inner Ø d1

®
®
● Max. bearing clearance reduced by 50% 78) According to igus testing method u Page 260 ● Max. bearing clearance reduced by 50% 78) According to igus testing method u Page 260
● Increased contact surface: longer service life Please note: Installation instructions u Page 187 ● Increased contact surface: longer service life Please note: Installation instructions u Page 187
Min. -50°C Min. -50°C
Max. +90°C Max. +90°C
Dimensions [mm] Dimensions [mm]

d1 d1 tolerance 78) d2 b1 r t Z Weight Part No. d1 d1 tolerance 78) d2 b1 r t Z Weight Part No.
[g] [g]
10 +0.000 +0.040 12 28 3.0 0.8 2.5 1.23 JUM-11-10 10 +0.000 +0.040 12 28 3.0 0.8 2.5 1.10 JUMO-11-10
12 +0.000 +0.040 14 31 3.0 0.8 3.0 1.65 JUM-11-12 12 +0.000 +0.040 14 31 3.0 0.8 3.0 1.50 JUMO-11-12
16 +0.000 +0.040 18 35 3.5 0.8 3.5 2.42 JUM-11-16 16 +0.000 +0.040 18 35 3.5 0.8 3.5 2.20 JUMO-11-16
20 +0.000 +0.040 23 44 5.0 0.8 3.5 5.49 JUM-11-20 20 +0.000 +0.040 23 44 5.0 0.8 3.5 4.90 JUMO-11-20
25 +0.000 +0.040 28 57 5.0 0.8 4.0 8.86 JUM-11-25 25 +0.000 +0.040 28 57 5.0 0.8 4.0 8.23 JUMO-11-25
30 +0.000 +0.050 34 67 5.0 0.8 4.0 16.63 JUM-11-30 30 +0.000 +0.050 34 67 5.0 0.8 4.0 14.95 JUMO-11-30
40 +0.000 +0.050 44 79 6.0 1.3 5.0 26.06 JUM-11-40 40 +0.000 +0.050 44 79 6.0 1.3 5.0 23.16 JUMO-11-40
50 +0.000 +0.060 55 99 7.0 1.3 6.0 48.82 JUM-11-50 50 +0.000 +0.060 55 99 7.0 1.3 6.0 45.35 JUMO-11-50

Housing hole for JUM-11 | Dimensions [mm] Housing hole for JUMO-11 | Dimensions [mm]
B B
Shaft di B r t f Z Part No. B / 2 Shaft di B W r t f Z Part No. B / 2
Ø H7 h10 +0.05 +0.1 +0.5 +0.2 Ø Z Ø H7 h10 +0,2 +0,05 +0,1 +0,5 +0,2 r
10 12 29 3.0 1.0 1.0 2.6 JUM-11-10 f 10 12 29 7.3 3.0 1.0 1.0 2.6 JUMO-11-10
12 14 32 3.0 1.0 1.5 3.1 JUM-11-12 12 14 32 9.0 3.0 1.0 1.5 3.1 JUMO-11-12 t
16 18 36 3.5 1.0 1.7 3.6 JUM-11-16 16 18 36 11.6 3.5 1.0 1.7 3.6 JUMO-11-16 Ø di
20 23 45 5.0 1.0 2.0 3.6 JUM-11-20 Ø di 20 23 45 12.0 5.0 1.0 2.0 3.6 JUMO-11-20
25 28 58 5.0 1.0 2.0 4.1 JUM-11-25 t 25 28 58 14.5 5.0 1.0 2.0 4.1 JUMO-11-25
30 34 68 5.0 1.0 2.0 4.1 JUM-11-30 30 34 68 16.6 5.0 1.0 2.0 4.1 JUMO-11-30
40 44 80 6.0 1.5 2.5 5.1 JUM-11-40 40 44 80 21.0 6.0 1.5 2.5 5.1 JUMO-11-40 Ø Z
50 55 100 7.0 1.5 2.5 6.1 JUM-11-50 r 50 55 100 25.5 7.0 1.5 2.5 6.1 JUMO-11-50 W

Can be combined with: Can be combined with: f

ASEAN 09/2023 ASEAN 09/2023

RJUM-01/-03 RJUM-06/-06-LL FJUM-01/-02 OJUM-01/-03 OJUM-06/-06-LL
TJUM-01/-03
190 Online tools and more information u www.igus-asean.com/drylinR 3D CAD files, prices and delivery time online u www.igus-asean.com/drylinR 191
