drylin R drylin R
®
®
®
®
shaft drylin R liners | Product range drylin R liners | Product range shaft
guides guides
Short, closed design for shafts - Long, closed design for shafts -
made from iglidur J (the all-rounder) made from iglidur J200 (the specialist)
®
®
Order key Order key
d2 d2
Y Y 2:1 Type Size Type Size
Y Y 2:1
Z
Z
b1 r t
d1 t
b1 r d1

iglidur ® J Liner Metric Compact Inner Ø d1 iglidur ® J200 Liner Metric Standard Inner Ø d1

®
The all-rounder for all shaft surfaces 78) According to igus testing method u Page 260 The "specialist" with the best running performance on 78) According to igus testing method u Page 260
®
in indoor and outdoor applications Please note: Installation instructions u Page 187 aluminium Please note: Installation instructions u Page 187
Min. -50°C Min. -50°C
Max. +90°C Max. +90°C
Dimensions [mm] Dimensions [mm]

d1 d1 tolerance 78) d2 b1 r t Z Weight Part No. d1 d1 tolerance 78) d2 b1 r t Z Weight Part No.
[g] [g]
[g]
10 +0.030 +0.070 12 25 3.0 0.8 2.5 1.02 JUM-02-10 10 +0.030 +0.070 12 28 3.0 0.8 2.5 1.10 J200UM-01-10
12 +0.030 +0.070 14 27 3.0 0.8 3.0 1.27 JUM-02-12 12 +0.030 +0.070 14 31 3.0 0.8 3.0 1.50 J200UM-01-12
16 +0.030 +0.070 18 29 3.5 0.8 3.5 1.82 JUM-02-16 16 +0.030 +0.070 18 35 3.5 0.8 3.5 2.54 J200UM-01-16
20 +0.030 +0.070 23 29 5.0 0.8 3.5 3.27 JUM-02-20 20 +0.030 +0.070 23 44 5.0 0.8 3.5 5.66 J200UM-01-20
25 +0.030 +0.070 28 39 5.0 0.8 4.0 5.75 JUM-02-25 25 +0.030 +0.070 28 57 5.0 0.8 4.0 9.51 J200UM-01-25
30 +0.040 +0.085 34 49 5.0 0.8 4.0 11.28 JUM-02-30 30 +0.040 +0.085 34 67 5.0 0.8 4.0 17.27 J200UM-01-30
40 +0.040 +0.085 44 59 6.0 1.3 5.0 17.94 JUM-02-40 40 +0.040 +0.085 44 79 6.0 1.3 5.0 26.75 J200UM-01-40
45 +0.040 +0.085 50 59 7.0 1.3 6.0 27.00 JUM-02-45 50 +0.050 +0.150 55 99 7.0 1.3 6.0 52.38 J200UM-01-50
50 +0.050 +0.150 55 69 7.0 1.3 6.0 32.56 JUM-02-50

Housing hole for JUM-02 | Dimensions [mm] Housing hole for J200UM-01 | Dimensions [mm]
B B
Shaft di B r t f Z Part No. B / 2 Shaft di B r t f Z Part No. B / 2
Ø H7 h10 +0.05 +0.1 +0.5 +0.2 Ø Z Ø H7 h10 +0.05 +0.1 +0.5 +0.2 Ø Z
10 12 26 3.0 1.0 1.0 2.6 JUM-02-10 10 12 29 3.0 1.0 1.0 2.6 J200UM-01-10 f
f
12 14 28 3.0 1.0 1.5 3.1 JUM-02-12 12 14 32 3.0 1.0 1.5 3.1 J200UM-01-12
16 18 30 3.5 1.0 1.7 3.6 JUM-02-16 16 18 36 3.5 1.0 1.7 3.6 J200UM-01-16
20 23 30 5.0 1.0 2.0 3.6 JUM-02-20 Ø di 20 23 45 5.0 1.0 2.0 3.6 J200UM-01-20 Ø di
25 28 40 5.0 1.0 2.0 4.1 JUM-02-25 25 28 58 5.0 1.0 2.0 4.1 J200UM-01-25 t
30 34 50 5.0 1.0 2.0 4.1 JUM-02-30 t 30 34 68 5.0 1.0 2.0 4.1 J200UM-01-30
40 44 60 6.0 1.5 2.5 5.1 JUM-02-40 40 44 80 6.0 1.5 2.5 5.1 J200UM-01-40
45 50 60 7.0 1.5 2.5 6.1 JUM-02-45 50 55 100 7.0 1.5 2.5 6.1 J200UM-01-50 r
50 55 70 7.0 1.5 2.5 6.1 JUM-02-50 r

Can be combined with: Can be combined with:

ASEAN 09/2023 ASEAN 09/2023

RJUM-02 RJUM-05/RJUME-05 FJUMT-01/-02 RJUM-01/-03 RJUM-06/-06-LL FJUM-01/-02
TJUM-05/RJUMT-05 TJUM-01/-03
192 Online tools and more information u www.igus-asean.com/drylinR 3D CAD files, prices and delivery time online u www.igus-asean.com/drylinR 193
