dryspin                                                                                                                                                                                                                   dryspin
                                                                                                                                                                                                                                        ®
              ®
                                   ®
      trapezoidal    dryspin  TR | Lead screw nuts | Product range                                                                                                                                                              trapezoidal
        thread                                                                                                                                                                                                                    thread
                     Injection-moulded lead screw nuts
                                                                                                                                       Order key
        Cylindrical (form S)                                  With flange (form F)

                                                                                                                                 Type           d2   b1   Thread



                                                                                                                                                                                      Options:
                                                                                                                                                                                      Form S: Cylindrical
                                                                                                                                                                                      Form F: With flange
                                                                                                                                   iglidur ®  material  Form F  Direction of rotation  Metric  Thread: injection moulding  Type  Thread type  Diameter [mm]  Pitch










                                                                                                                                       Completely injection-moulded lead screw nut
                                                                                                                                       (off-the-tool) incl. injection-moulded thread















        Technical data                                                                                                           Dimensions [mm]

         Thread                     Direction of rotation        Effective           Pitch         Max. static                        d1 156)        d2 156)          A             b1 156)        Weight     Part No.
                                    Right         Left      supporting surface         P             axial F
                                                                   [mm ]              [mm]             [N]                                                                                           [g]
                                                                      2
         Cylindrical (form S)
         Tr8x1.5                      ●            –               228                1.5            500 43)                            8             20              19             20             7.86      JSRM-M-01-TR8X1.5
         Tr10x2                       ●            –               283                 2             1,131                             10             20              19             20             7.02      JSRM-M-01-TR10X2
         Tr12x3                       ●            –               412                 3             1,649                             12             24             22.6            25            12.64      JSRM-M-01-TR12X3 New
         Tr16x2                       ●            –               589                 2             2,356                             16             28             26.2            25            15.45      JSRM-M-01-TR16X2 New
         Tr16x4                       ●            –               550                 4             2,199                             16             28            26.16            25            15.45      JSRM-M-01-TR16X4


         With flange (form F)                                                                                                       d1      d2       A        B       C       d5       b1      b2       [g]
         Tr8x1.5                       ●               –              118             1.5             471                           8       20      19.0     20       30      4.2      20      5.5     7.38   JFRM-M-01-TR8X1.5
         Tr10x2                        ●               –              228              2              911                           10      20      19.0     20       30      4.2      20      5.5     7.38   JFRM-M-01-TR10X2
         Tr12x3                        ●               –              412              3             1,649                          12      24      22.6     24       34      5.0      25      6.0     10.3   JFRM-M-01-TR12X3 New
         Tr16x2                        ●               –              589              2             2,356                          16      28      25.5     27       38      6.0      25      6.5    13.99   JFRM-M-01-TR16X2 New
         Tr16x4                        ●               –              353              4             1,414                          16      28      25.5     27       38      6.0      25      6.5    13.99   JFRM-M-01-TR16X4
        43)  Reduced load due to nut geometry                                                                                    156)  Tolerances according to DIN ISO 2768-1, tolerance class m (medium)






                                                                                                                   ASEAN 09/2023  ASEAN 09/2023




        450 Online tools and more information u www.igus-asean.com/drylinTR                                                               3D CAD files, prices and delivery time online u www.igus-asean.com/drylinTR               451
