drylin R drylin R
®
®
®
®
shaft drylin R liners | Product range New drylin R liners | Product range New shaft
guides guides
Long, open design for supported shafts - made from iglidur A160 Short, closed design for round shafts - made from iglidur A160
®
®
(compliant with Regulation (EU) No. 10/2011 and FDA guidelines) (compliant with Regulation (EU) No. 10/2011 and FDA guidelines)
Order key d2 Order key
d2
Type Size Y Y 2:1 Type Size
Y Y 2:1 Z
Z
t
b1 r
d1
b1 r t
d1
iglidur ® A160 Liner Metric Open Standard Inner Ø d1 iglidur ® A160 Liner Metric Compact Inner Ø d1

Compliant with Regulation (EU) No. 10/2011 and FDA 78) According to igus testing method u Page 260 Compliant with Regulation (EU) No. 10/2011 and FDA 78) According to igus testing method u Page 260
®
®
guidelines for longer service life on hardened stainless Please note: Installation instructions u Page 187 guidelines for longer service life on hardened stainless Please note: Installation instructions u Page 187
steel shafts Min. -50°C steel shafts Min. -50°C
Max. +90°C Max. +90°C
Dimensions [mm] Dimensions [mm]

d1 d1 tolerance 78) d2 b1 r t Z Weight Part No. d1 d1 tolerance 78) d2 b1 r t Z Weight Part No.
[g] [g]
10 +0.000 +0.020 12 28 3.0 0.8 2.5 1.08 A160UMO-01-10 New 10 +0.030 +0.070 12 25 3.0 0.8 2.5 1.02 A160UM-02-10 New
12 +0.030 +0.070 14 31 3.0 0.8 3.0 1.47 A160UMO-01-12 New 12 +0.030 +0.070 14 27 3.0 0.8 3.0 1.27 A160UM-02-12 New
16 +0.030 +0.070 18 35 3.5 0.8 3.5 2.16 A160UMO-01-16 New 16 +0.030 +0.070 18 29 3.5 0.8 3.5 1.82 A160UM-02-16 New
20 +0.030 +0.070 23 44 5.0 0.8 3.5 4.80 A160UMO-01-20 New 20 +0.030 +0.070 23 29 5.0 0.8 3.5 3.27 A160UM-02-20 New
25 +0.030 +0.070 28 57 5.0 0.8 4.0 8.07 A160UMO-01-25 New 25 +0.030 +0.070 28 39 5.0 0.8 4.0 5.75 A160UM-02-25 New
30 +0.040 +0.085 34 67 5.0 0.8 4.0 14.65 A160UMO-01-30 New 30 +0.040 +0.085 34 49 5.0 0.8 4.0 11.28 A160UM-02-30 New
40 +0.040 +0.085 44 79 6.0 1.3 5.0 22.70 A160UMO-01-40 New 40 +0.040 +0.085 44 59 6.0 1.3 5.0 17.94 A160UM-02-40 New
50 +0.050 +0.150 55 69 7.0 1.3 6.0 32.56 A160UM-02-50 New

Housing hole for A160UM-01 | Dimensions [mm] Housing hole for A160UM-02 | Dimensions [mm]
B B
Shaft di B W r t f Z Part No. B / 2 Shaft di B r t f Z Part No. B / 2
Ø H7 h10 +0.5 +0.05 +0.1 +0.2 r Ø H7 h10 +0.05 +0.1 +0.5 +0.2 Ø Z
10 12 29 7.3 3.0 1.0 1.0 2.6 A160UMO-01-10 New 10 12 26 3.0 1.0 1.0 2.6 A160UM-02-10 New
f
12 14 32 9.0 3.0 1.0 1.5 3.1 A160UMO-01-12 New t 12 14 28 3.0 1.0 1.5 3.1 A160UM-02-12 New
16 18 36 11.6 3.5 1.0 1.7 3.6 A160UMO-01-16 New Ø di 16 18 30 3.5 1.0 1.7 3.6 A160UM-02-16 New
20 23 45 12.0 5.0 1.0 2.0 3.6 A160UMO-01-20 New 20 23 30 5.0 1.0 2.0 3.6 A160UM-02-20 New Ø di
25 28 58 14.5 5.0 1.0 2.0 4.1 A160UMO-01-25 New 25 28 40 5.0 1.0 2.0 4.1 A160UM-02-25 New
30 34 68 16.6 5.0 1.0 2.0 4.1 A160UMO-01-30 New 30 34 50 5.0 1.0 2.0 4.1 A160UM-02-30 New t
40 44 80 21.0 6.0 1.5 2.5 5.1 A160UMO-01-40 New Ø Z 40 44 60 6.0 1.5 2.5 5.1 A160UM-02-40 New
W
50 55 70 7.0 1.5 2.5 6.1 A160UM-02-50 New
r

Can be combined with: Can be combined with:
f
ASEAN 09/2023 ASEAN 09/2023

OJUM-01/-03 OJUM-06/-06-LL RJUM-02 RJUM-05/RJUME-05 FJUMT-01/-02
TJUM-01/-03 TJUM-05/RJUMT-05
204 Online tools and more information u www.igus-asean.com/drylinR 3D CAD files, prices and delivery time online u www.igus-asean.com/drylinR 205
