drylin R drylin R
®
®
®
®
shaft drylin R liners | Product range drylin R liners | Product range shaft
guides guides
Long, open design for supported shafts - Long, closed design for round shafts - made from iglidur A160
®
made from iglidur A180 (FDA-compliant) (compliant with Regulation (EU) No. 10/2011 and FDA guidelines)
®
Order key d2 Order key
d2
Type Size Y Y 2:1 Type Size
Y Y 2:1 Z
Z
t
b1 r
d1
b1 r t
d1
iglidur ® A180 Liner Metric Open Standard Inner Ø d1 iglidur ® A160 Liner Metric Standard Inner Ø d1

The FDA-compliant for the food 78) According to igus testing method u Page 260 Compliant with Regulation (EU) No. 10/2011 and FDA 78) According to igus testing method u Page 260
®
®
and pharmaceutical industry Please note: Installation instructions u Page 187 guidelines for longer service life on hardened stainless Please note: Installation instructions u Page 187
Min. -50°C steel shafts Min. -50°C
Max. +90°C Max. +90°C
Dimensions [mm] Dimensions [mm]

d1 d1 tolerance 78) d2 b1 r t Z Weight Part No. d1 d1 tolerance 78) d2 b1 r t Z Weight Part No.
[g] [g]
10 +0.000 +0.020 12 28 3.0 0.8 2.5 1.08 A180UMO-01-10 10 +0.03 +0.07 12 28 3.0 0.8 2.5 0.7 A160UM-01-10
12 +0.030 +0.070 14 31 3.0 0.8 3.0 1.47 A180UMO-01-12 12 +0.03 +0.07 14 31 3.0 0.8 3.0 1.0 A160UM-01-12
16 +0.030 +0.070 18 35 3.5 0.8 3.5 2.16 A180UMO-01-16 16 +0.03 +0.07 18 35 3.5 0.8 3.5 1.5 A160UM-01-16
20 +0.030 +0.070 23 44 5.0 0.8 3.5 4.80 A180UMO-01-20 20 +0.03 +0.07 23 44 5.0 0.8 3.5 3.3 A160UM-01-20
25 +0.030 +0.070 28 57 5.0 0.8 4.0 8.07 A180UMO-01-25 25 +0.03 +0.07 28 57 5.0 0.8 4.0 5.4 A160UM-01-25
30 +0.040 +0.085 34 67 5.0 0.8 4.0 14.65 A180UMO-01-30 30 +0.04 +0.09 34 67 5.0 0.8 4.0 9.9 A160UM-01-30
40 +0.040 +0.085 44 79 6.0 1.3 5.0 22.70 A180UMO-01-40 40 +0.04 +0.09 44 79 6.0 1.3 5.0 17.3 A160UM-01-40
50 +0.05 +0.15 55 99 7.0 1.3 6.0 36.3 A160UM-01-50

Housing hole for A180UMO-01 | Dimensions [mm] Housing hole for A160UM-01 | Dimensions [mm]
B B
Shaft di B W r t f Z Part No. B / 2 Shaft di B r t f Z Part No. B / 2
Ø H7 h10 +0.5 +0.05 +0.1 +0.2 r Ø H7 h10 +0.05 +0.1 +0.5 +0.2 Ø Z
10 12 29 7.3 3.0 1.0 1.0 2.6 A180UMO-01-10 10 12 29 3.0 1.0 1.0 2.6 A160UM-01-10 f
12 14 32 9.0 3.0 1.0 1.5 3.1 A180UMO-01-12 t 12 14 32 3.0 1.0 1.5 3.1 A160UM-01-12
16 18 36 11.6 3.5 1.0 1.7 3.6 A180UMO-01-16 Ø di 16 18 36 3.5 1.0 1.7 3.6 A160UM-01-16
20 23 45 12.0 5.0 1.0 2.0 3.6 A180UMO-01-20 20 23 45 5.0 1.0 2.0 3.6 A160UM-01-20 Ø di
25 28 58 14.5 5.0 1.0 2.0 4.1 A180UMO-01-25 25 28 58 5.0 1.0 2.0 4.1 A160UM-01-25 t
30 34 68 16.6 5.0 1.0 2.0 4.1 A180UMO-01-30 30 34 68 5.0 1.0 2.0 4.1 A160UM-01-30
40 44 80 21.0 6.0 1.5 2.5 5.1 A180UMO-01-40 Ø Z 40 44 80 6.0 1.5 2.5 5.1 A160UM-01-40
W
50 55 100 7.0 1.5 2.5 6.1 A160UM-01-50 r

Can be combined with: Can be combined with:
f
ASEAN 09/2023 ASEAN 09/2023

OJUM-01/-03 OJUM-06/-06-LL RJUM-01/-03 RJUM-06/-06-LL FJUM-01/-02
TJUM-01/-03 TJUM-01/-03
202 Online tools and more information u www.igus-asean.com/drylinR 3D CAD files, prices and delivery time online u www.igus-asean.com/drylinR 203
