       dryspin       dryspin  technology | Lead screw nuts | Product range                                                                                                                                                       dryspin
                                                                                                                                                                                                                                        ®
              ®
      technology                                                                                                                                                                                                                technology
                     Cost-effective injection-moulded lead screw nuts, cylindrical (form S)
                                                                                                                                       Order key


                                                                                                                                 Type                   d2   b1   Thread



                                                                                                                                                                                                         Options:
                                                                                                                                                                                                         Direction of rotation
                                                                                                                                    dryspin ®  technology  iglidur ®  material  Form S  Direction of rotation  Metric  Thread: cut  Thread type  Diameter [mm]  Pitch
        Image exemplary                                                                                                                                                                                  R: Right-hand thread
                                                                                                                                                                                                         L: Left-hand thread




                                                                                                                                                               Type



                                                                                                                                                    J     High efficiency at all speeds                  Standard 24hrs
                                                                                                                                                    E7    For high speeds and low loads                  Optional



        Technical data                                                                                                           Dimensions [mm]

         Thread              Direction of rotation       Effective         Pitch         Max. stat. axial F [N]                     d1 156)   d2 156)      A        b1 156)       Weight [g]      Part No.
                             Right         Left     supporting surface       P                 iglidur ®                                                                           iglidur ®
                                                           [mm ]            [mm]           J            E7                                                                       J         E7
                                                              2
         Ds4x2.4              ●             –               53              2.4          132            26                           4          12        11.0       12        1.80       1.27    DST-   SRM-C-01-DS4X2.4
         Ds5x5                ●             –               53               5           133            27                           5          12        11.0       12        1.67       1.18    DST-   SRM-C-01-DS5X5
         Ds5x10               ●             –               40              10           100            20                           5          12        11.0       12        1.67       1.18    DST-   SRM-C-01-DS5X10          New
         Ds6.35x1             ●             –              110               1           276            55                          6.35        12        11.0       12        1.46       1.03    DST-   SRM-C-01-DS6.35X1        New
         Ds6.35x2.54          ●             ●              159              2.54         397            79                          6.35        12        11.0       12        1.46       1.03    DST-   S   M-C-01-DS6.35X2.54
         Ds6.35x5.08          ●             –              125              5.08         312            62                          6.35        12        11.0       12        1.46       1.03    DST-   SRM-C-01-DS6.35X5.08
         Ds6.35x6.35          ●             –               96              6.35         240            48                          6.35        12        11.0       12        1.46       1.03    DST-   SRM-C-01-DS6.35X6.35     New
         Ds6.35x12.7          ●             –               64              12.7         159            32                          6.35        12        11.0       12        1.46       1.03    DST-   SRM-C-01-DS6.35X12.7
         Ds6.35x25.4          ●             –               70              25.4         174            35                          6.35        12        11.0       12        1.46       1.03    DST-   SRM-C-01-DS6.35X25.4
         Ds8x8                ●             –              240               8           601           120                           8          20        18.0       20        7.86       5.54    DST-   SRM-C-01-DS8X8           New
         Ds8x10               ●             ●              203              10           507           101                           8          20        18.0       20        7.86       5.54    DST-   S   M-C-01-DS8X10
         Ds8x15               ●             ●              203              15           507           101                           8          20        18.0       20        7.86       5.54    DST-   S   M-C-01-DS8X15
         Ds8x24               ●             –              173              24           430            86                           8          20        18.0       20        7.86       5.54    DST-   SRM-C-01-DS8X24
         Ds8x40               ●             –               95              40           238            48                           8          20        18.0       20        7.86       5.54    DST-   SRM-C-01-DS8X40          New
         Ds10x2               ●             ●              299               2           1,196         149                           10         20        18.0       20        7.02       4.95    DST-   S   M-C-01-DS10X2        New
         Ds10x3               ●             ●              402               3           1,608         201                           10         20        18.0       20        7.02       4.95    DST-   S   M-C-01-DS10X3        New
         Ds10x12              ●             ●              274              12           686           137                           10         20        18.0       20        7.02       4.95    DST-   S   M-C-01-DS10X12
         Ds10x25              ●             ●              249              25           623           125                           10         20        18.0       20        7.02       4.95    DST-   S   M-C-01-DS10X25
         Ds10x50              ●             ●              144              50           361            72                           10         20        18.0       20        7.02       4.95    DST-   S   M-C-01-DS10X50
         Ds12x3               ●             –              439               3           1,756         220                           12         24        22.6       25        12.64      8.91    DST-   SRM-C-01-DS12X3          New
         Ds12x5               ●             –              407               5           1,629         204                           12         24        22.6       25        12.64      8.91    DST-   SRM-C-01-DS12X5
         Ds12.7x12.7          ●             –              428              12.7         1,069         214                          12.7        24        22.6       25        12.13      8.55    DST-   SRM-C-01-DS12.7X12.7
         Ds12x15              ●             –              400              15           998           200                           12         24        22.6       25        12.64      8.91    DST-   SRM-C-01-DS12X15
         Ds12x25              ●             ●              399              25           1,069         200                           12         26        22.6       25        12.64      8.91    DST-   S   M-C-01-DS12X25       New
         Ds14x4               ●             –              476               4           1,905         238                           14         24        22.6       25        11.00     12.12    DST-   SRM-C-01-DS14X4          New
                                                                                                                   ASEAN 09/2023  ASEAN 09/2023  156)  Tolerances according to DIN ISO 2768-1, tolerance class m (medium)
