profile drylin W profile guides | Product range drylin W profile guides | Product range profile
C4
guides C6 C1 C1 C5 guides
C3
Double rails, round, hard-anodised and clear-anodised aluminium C6 C3 C5
A3
C4 A3
G1
C1 Order key
G2 G1
C6 C3 C5 G2
b K1 A3 Type Option
b K1
G1
G2
b K1 Option:
L CA: Clear anodised
L
L Optional:
B y x Econ series with clear
B ! Coz- y z x Profile rail, round anodising (silver)
K2 di z y x Rail width [mm] Clear anodised
! Coz- z
WS-10-30 WS-10-30-CA WJ200UM-01-.. K2 di
WJ200UM-01-.. Shaft Ø
B h2 h1 y x da da H ! Coz- ! Coz- Q2
Hard-anodised surfaces K2 ! Coz- a1 h2 h1 di z H h h Q2
WS-..
u Page 43 WJ200UM-01-.. WS-.. A1 A1 a a1 di di
a
h2 h1 da H ! Coz- Q1 Q1 Q2
Clear anodised surface a1 h
di
u Page 43 WS-.. A1 a This orientation not possible for
Q1
WS-10-30/WS-10-40/
Curved rail profiles WS-10-80/WS-10-120
u Page 48

Technical data and dimensions [mm]
Part No. Weight H 57) da di L a A1 b h h1 h2 G1 G2 a1 62) Q1 Q2 C4 C5 C6 K1 for Surface inertia- Moment of
screw moment resistance
±0.25 max. min. max. min. max. DIN 912 ly lz Wby Wbz
4
4
3
3
[kg/m] [mm ] [mm ] [mm ] [mm ]
WS-10-30 0.85 18 10-0.1 – 4,000 30-0.5 16.5 30 5.5 5.5 58) 9 25 15 – – – 120 20 79.5 20 79.5 M5 58) 47,500 4,400 2,370 540
WS-10-30-CA New 0.85 18 10 – 4,000 30 -0.5 16.5 30 5.5 5.5 9 25 15 – – – 120 20 79.5 20 79.5 M5 58) 47,500 4,400 2,370 540
WS-10-40 1.00 18 10-0.1 – 4,000 40-0.5 16.5 40 5.5 5.5 58) 9 30 20 – – – 120 20 79.5 20 79.5 M6 58) 91,000 5,100 3,600 590
WS-10-40-CA New 1.00 18 10 – 4,000 40 -0.5 16.5 40 5.5 5.5 9 30 20 – – – 120 20 79.5 20 79.5 M6 58) 91,000 5,100 3,600 590
WS-10-80 1.50 18 10-0.1 – 4,000 74-0.7 16.5 74 5.5 5.5 58) 9 27 17 40 – – 120 20 79.5 20 79.5 M6 58) 388,000 6,100 9,200 650
WS-10-80-CA New 1.50 18 10 – 4,000 74 -0.7 16.5 74 5.5 5.5 9 27 17 40 – – 120 20 79.5 20 79.5 M6 58) 388,000 6,100 9,200 650
WS-10-120 2.02 18 10-0.1 – 4,000 120-0.7 16.5 120 5.5 5.5 58) 9 30 20 80 – – 120 20 79.5 20 79.5 M6 58) 1,303,000 7,100 20,000 720
WS-10-120-CA New 2.02 18 10 – 4,000 120 16.5 120 5.5 5.5 9 30 20 80 – – 120 20 79.5 20 79.5 M6 58) 1,303,000 7,100 20,000 720
WS-16-60 1.96 27 16-0.1 8.0 4,000 54-0.5 25.0 58 7.5 3.5 14 43 29 – 32 28 120 20 79.5 20 79.5 M8 367,600 26,100 9,900 1,900
WS-16-60-CA New 1.96 27 16 8.0 4,000 54 -0.5 25.0 58 7.5 3.5 14 43 29 – 32 28 120 20 79.5 20 79.5 M8 367,600 26,100 9,900 1,900
WS-16-120 New 3.14 27 16-0.1 8.0 4,000 116-0.4 25.0 120 7.5 3.5 14 34 20 80 33 28 120 20 79.5 20 79.5 M8 2,114,000 33,200 31,100 2,150
WS-20-80 3.30 36 20-0.1 10.2 4,000 74-0.7 30.0 82 9.5 4.5 20 38 21 40 37 37 120 20 79.5 20 79.5 M8 1,080,000 78,700 21,000 4,000
WS-20-80-CA New 3.30 36 20 10.2 4,000 74 -0.7 30.0 82 9.5 4.5 20 38 21 40 37 37 120 20 79.5 20 79.5 M8 1,080,000 78,700 21,000 4,000
WS-25-120 5.8 45 25-0.15 14.0 4,000 120-0.7 37.5 131 11.5 5.5 25 46.5 25.5 80 45.5 46 150 25 99.5 25 99.5 M10 4,867,000 215,000 62,400 8,500

57) Height dimension minus the bearing clearance tolerance
58) Plain holes
62) WS-10-40/-16-60 a single row of mounting holes down the centreline; WS-10-80/-10-120/-20-80/-25-120 two
parallel rows of mounting holes
Standard hole pattern: C5 = C6, please order with drawing for C5 ≠ C6.
