chainfi x strain relief | Parameters | Overview

CFN nuggets Strain relief CFV - CFB -
separators strain relief element strain relief
connector system
For all KMA* with C-profi le E2/000, E2 e-tubes, E2/000, R2.1, E4, E6, for all KMA*
or top-hat (DIN) rail 35 E6, T3 E4.1L, E4.1 with C-profi le
*Plastic metal mounting bracket *Plastic metal mounting bracket

Cost-eff ective, fast strain relief Combination of separator For both e-chains ® and Space-saving, modular strain
for simpler application with and strain relief, ideal for small e-tubes. Stepped strain relief relief with many cables in
small spaces and medium spaces. For applications with for use outside of the energy confi ned spaces. For applications
accelerations. Also available medium accelerations. For chain cross section - even with high accelerations and loads
as single parts for fixed small cable diameters. Ideal with different connectors. e.g. machine tools.
applications, e.g. in cabinets, for e-tubes. For machine tools A subsequent installation is
etc. and automation. possible. Easy installation in a
top-hat (DIN) rail 15 (TS92.31)
or in the C-profi le of the KMA
mounting brackets.

For high loads For high loads For high loads No limitation

+ – + + + + –
– – – +

yes yes yes yes (special fabrication)
high high medium high to very high

3D-CAD, confi gurators, service life calculation and more www.igus-asean.com/chainfi x 1405
