chainfi x strain relief | Clamps chainfix

Product range and materials For the following
● Steel clamp: clamp and screw black painted steel igus series
®
● Stainless steel clamp: clamp and screw: blank (material 1.4301/AISI 304) E2.1
● Stacker elements: bottom saddle and stacker saddle (igumid ® G material) ● E2.38
● Steel C-profi le available (material galvanised steel) ● E2.48
● Stainless steel C-profi le available (material 1.4301/AISI 304) E2/000
● 2600/2700/2650/2680
Installation height ● 3400/3500/3450/3480
If the e-chain ® glides on itself for long travels, the screw heads of the strain relief at the fi xed end E4.1L
of the e-chain ® must have a distance of at least 10mm from the top of the e-chain ® . As a result, ● E4.38L/R4.38L
many strain relief elements described here may not be suitable for use at the fi xed end on long ● E4.48L/R4.48L
gliding e-chains ® . For unsupported e-chains ® , strain relief elements can always be safely used. ● E4.64L
E4Q
● E4Q.34/H4Q.34
● E4Q.44/H4Q.44
● E4Q.58/H4Q.58
● E4Q.82/H4Q.82
E4.1
Please note ● E4.32/H4.32/R4.32
● The cables should ideally be fi xed at both ends of the e-chain ® . ● E4.42/H4.42/R4.42
As a minimum they need to be attached at the moving end of the e-chain ® ! ● E4.56/H4.56/R4.56
● When using chainfix clamps on C-profiles in the mounting bracket for the series ● E4.80/H4.80/R4.80
E4.38L/R4.38L, E4Q.34/H4Q.34, E4.32/H4.32/R4.32 (also for the classic series ● E4.112/R4.112
280/290/R770, 2828/2928/R7728), a shortened bottom saddle must be used. For ● E4.162
shortened bottom saddles, please add the part number with index K. Example: E4/light
Part No. CFX12.1K ● 14040/14140/18840
● 14240/14340
● 14550/14650/19050
● 15050/15150/19850
● 15250/15350
E6.1
● E61.40
● E61.52
● E61.62
● E61.80
E6
CFX - reduced installation height due to Save both time and space during installation ● E6.40
threaded pin and optimal housing height with igus ® chainfi x clamps ● E6.52/R6.52
● E6.62
● E6.80L
● E6.80

3D-CAD, confi gurators, service life calculation and more www.igus-asean.com/chainfi x 1409
