chainfi x strain relief | Tests and proof                             chainfix




                        igus  chainfi x strain relief devices are tested in the in-house igus  laboratory under
                                                                                 ®
                            ®
                        real-world conditions, taking many parameters into account
                        Whether under the infl uence of fl uids like water or oil, or at diff erent ambient temperatures. The interaction of chainfi x systems with
                        diff erent jacket materials of cables and hoses plays a big role in the in-house test program.


























                        igus ®  tensile strength test CFX clamps with stacker saddle.   Comparison test of three different strain relief systems.
                        Conclusion: the tensile strength of igus ®  chainfi x clamps is three   Conclusion: the tensile strength of igus ®  chainfi x clamps is three
                        times higher when compared with conventional strain relief  times higher when compared with conventional strain relief

















                        Tensile strength tests with chainfl ex ®  cables  Tensile strength tests of igus ®  chainfi x tiewrap plate with cable
                                                               tiewraps
